Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 400, Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy
Suspension Fork
Genesis Chromoly With Anything Cage Mounts
Drivetrain
Rear Derailleur
Shimano GRX RD-RX400 10 Speed
Front Derailleur
Shimano GRX FD-RX400
Shift Levers
Shimano Tiagra ST-R4700 10 Speed
Cassette
Shimano CS-HG500-10 11-34T
Bottom Bracket
BB-ES300
Chain
KMC X10
Pedals
NW-91K With Cage
Wheels
Front Hub
KT-K68
Rear Hub
KT-K68
Rims
Shining DB-31 32H
Spokes
Steel 14 g
Tires
WTB Riddler Comp 700 x 37c
Brakes
Brakes
Promax DSK-717 Mechanical Disc
Brake Levers
Shimano Tiagra ST-R4700 10 Speed
Cockpit
Stem
Genesis Alloy 31.8mm -6 deg 100 mm
Headset
PT-1606 EC34 Upper / EC34 Lower
Seat
Saddle
Genesis
Seatpost
Genesis Alloy 27.2 x 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.54 mm | 1.55 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Stack | 570 mm | 591 mm | 610 mm |
| Reach | 373 mm | 383 mm | 393 mm |
| Top Tube Length | 542 mm | 559 mm | 580 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 500 mm | 530 mm | 550 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 135 mm | 155 mm | 175 mm |
| Wheelbase | 1021 mm | 1033 mm | 1050 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 73 mm |
| Standover Height | 782 mm | 806 mm | 824 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Cda 30 is part of the Genesis Cda model. 15 bikes variations carry this model name so far. Take a sneak peek at all Genesis Cda bikes models from 2023, by clicking here.
Model range prices
Genesis Cda 10 2023 is the cheapest bike model and costs 972$. Genesis Cda 30 2023 is the most expensive one and costs 1337$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2023 and its price was 1337$. Doing a quick comparison, we notice that Cda 30 price is 84.14% lower than the average cost of a Gravel bike.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
The Cda 30 2023 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Genesis Cda 30 has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Genesis Cda 30 bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
