Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Titanium -
Wheels 700c -
Suspension Rigid
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
3AL-2.5V Double-Butted Titanium
Suspension Fork
Genesis Carbon CX w/ 1-1/2" - 1-1/8" Tapered Steerer w/ 12mm TA
Drivetrain
Front Derailleur
34.9mm Band-on (not incl.)
Bottom Bracket
BSA 68mm (not incl.)
Cockpit
Headset
Prestine PT-1860 1-1/8" - 1-1/2" tapered
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.52 mm | 1.53 mm | 1.54 mm | 1.56 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm | 276 mm | 276 mm |
| Front Center | 587 mm | 604 mm | 616 mm | 631 mm | 643 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 69 mm | 69 mm | 66 mm | 66 mm | 63 mm |
| Stack | 553 mm | 572 mm | 593 mm | 612 mm | 633 mm |
| Reach | 367 mm | 377 mm | 387 mm | 397 mm | 407 mm |
| Top Tube Length | 525 mm | 546 mm | 562 mm | 584 mm | 606 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 550 mm | 580 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° | 71.5 ° | 72 ° |
| Head Tube Length | 125 mm | 145 mm | 165 mm | 185 mm | 205 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1008 mm | 1025 mm | 1037 mm | 1053 mm | 1065 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 73 mm | 73 mm | 73 mm |
| Standover Height | 763 mm | 786 mm | 810 mm | 828 mm | 852 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Croix De Fer Ti FS completes the Genesis Croix model. Genesis launched 58 frames of this model so far. Take a sneak peek at all Genesis Croix frames models from 2018, by clicking here.
Model range prices
Genesis Croix De Fer FS 2018 is the most economical model, with a starting price of 607$. Genesis Croix De Fer Ti FS 2018 on the other hand costs 2796$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel frames average price
Our math shows that the average cost of a dependable Gravel frame is 1505$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel frame. In short, before purchasing your ideal frame do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2796$. In conclusion, this frame price is 85.78% more expensive than the price of the average Gravel frame.
Croix De Fer Ti FS components
Fork material
The fork on this frame is made out of carbon, so, it’s a great addition to the frame’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Sizes
Croix De Fer Ti FS comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
