Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Rival, Rival 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
24/30T Modulus Carbon Road Disc w/ Tapered Headtube & Fully Internal Cable Routing
Suspension Fork
Full Carbon Fork w/ 1-1/2" - 1-1/8" Tapered Steerer w/ 12mm TA
Drivetrain
Rear Derailleur
SRAM Rival 1x / Long cage
Shift Levers
SRAM Rival / 1x11 speed
Cassette
SRAM PG1130 / 11-42T
Crank
SRAM Rival 1 XSYNC / 42T / XS, 170mm / S-M, 172.5mm / L-XL, 175mm
Bottom Bracket
SRAM PF-GXP
Chain
KMC x11
Wheels
Front Hub
Formula RX-812/RX-300 28h / front 12mm TA / rear 12mm TA / 6-bolt
Rear Hub
Formula RX-812/RX-300 28h / front 12mm TA / rear 12mm TA / 6-bolt
Rims
Jalco XCD22 / 28h
Spokes
Stainless steel 14g
Tires
WTB Exposure 700x32c w/skinwall
Brakes
Brakes
SRAM Rival hydraulic brakes w/160mm SRAM Centerline rotors
Brake Levers
SRAM Rival 1x Hydraulic
Cockpit
Stem
Genesis Code 7 / -7deg / XS, 90mm / S-M, 100mm / L-XL, 110mm
Handlebar
Genesis X-Race Pro / 16deg Flare / XS, 400mm / S-M, 420mm / L-XL, 440mm
Headset
FSA Orbit C-40-ACB, NO.42
Seat
Saddle
Genesis Road Comfort
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.51 mm | 1.53 mm | 1.53 mm | 1.54 mm |
| Bottom Bracket Height | 277 mm | 277 mm | 277 mm | 277 mm | 277 mm |
| Front Center | 576 mm | 592 mm | 607 mm | 623 mm | 640 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 59 mm | 59 mm | 59 mm | 59 mm | 59 mm |
| Stack | 536 mm | 555 mm | 577 mm | 594 mm | 613 mm |
| Reach | 357 mm | 367 mm | 377 mm | 387 mm | 397 mm |
| Top Tube Length | 518 mm | 534 mm | 553 mm | 571 mm | 587 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.25 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 540 mm | 570 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 115 mm | 135 mm | 155 mm | 175 mm | 195 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 977 mm | 993 mm | 1009 mm | 1025 mm | 1042 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 744 mm | 769 mm | 793 mm | 808 mm | 831 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Datum completes the Genesis Datum model. There are 6 bikes that carry this model name. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Genesis Datum 20 W 2018 is the most economical model, with a starting price of 2918$. Genesis Datum 2018 on the other hand costs 3040$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2018 for 3040$. If we compare this with the average Gravel bike cost we notice that the price is 23.48% more expensive.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Datum components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
As for the wheels, Genesis Datum 2018, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Genesis Datum has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
