Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris, Shimano -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALX8 6066/6061-T6 Double-Butted Aluminium
Suspension Fork
Carbon Road w/ 1-1/2"-1-1/8" Tapered Alloy Steerer
Drivetrain
Rear Derailleur
Shimano Claris RD-R2000 / SS cage
Front Derailleur
Shimano Claris FD-R2000
Shift Levers
Shimano Claris ST-R2000 2x8 speed
Cassette
Shimano CS-HG41-8 / 11-32T
Crank
Shimano FC-RS200 / 50-34T / XS-S, 170mm / M-XL, 175mm
Bottom Bracket
Shimano BB-UN26 68-110mm
Chain
KMC x8
Pedals
NW-91K w/ Toeclip
Wheels
Front Hub
KT 5P5F/G5ER 28h / front / rear
Rear Hub
KT 5P5F/G5ER 28h / front / rear
Rims
Jalco MRX-24 / 28h
Spokes
Steel 14g
Tires
CST Compressor 700x25c 60TPI
Brakes
Brakes
Tektro R-315 57mm drop
Brake Levers
Shimano Claris ST-R2000
Cockpit
Stem
Genesis AS-007 / + - 7deg / XS, 90mm / S-M, 100mm / L-XL, 110mm
Handlebar
Genesis alloy / 125mm drop x 70mm reach / XS, 400mm / S-M, 420mm / L-XL, 440mm
Headset
Prestine PT-F23 1-1/8" - 1-1/2" tapered
Seat
Saddle
Genesis Road Comfort
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.5 mm | 1.51 mm | 1.53 mm | 1.54 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 583 mm | 596 mm | 611 mm | 622 mm | 639 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 62 mm | 59 mm | 59 mm | 56 mm | 56 mm |
| Stack | 530 mm | 551 mm | 570 mm | 591 mm | 610 mm |
| Reach | 357 mm | 367 mm | 377 mm | 387 mm | 397 mm |
| Top Tube Length | 511 mm | 533 mm | 548 mm | 570 mm | 586 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 540 mm | 570 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 130 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 984 mm | 997 mm | 1013 mm | 1024 mm | 1041 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 750 mm | 773 mm | 795 mm | 814 mm | 837 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Delta 10 MGT completes the Genesis Delta model. 15 bikes variations carry this model name so far. You can get a glimpse at all models from 2018, by clicking on this link.
Model range prices
Genesis Delta 24 2018 is the cheapest bike model and costs 522$. Genesis Delta 20 W 2018 is the most expensive one and costs 882$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Endurance bikes average price
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, even if your budget is less than the average, you might still be able to get a top-quality Endurance bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 699$. If we compare this with the average Endurance bike cost we notice that the price is 235.62% smaller.
Delta 10 MGT components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
When leaving the production line, the Delta 10 MGT model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
Genesis Delta 10 MGT bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
