Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris, Shimano -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Rim
Sizing
Recommended size guide.
XXS
145cm - 159cm
XS
157cm - 168cm
SM
165cm - 176cm
MD
174cm - 183cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALX8 6066/6061-T6 Double-Butted Aluminium
Suspension Fork
Carbon Road w/ 1-1/2"-1-1/8" Tapered Alloy Steerer
Drivetrain
Rear Derailleur
Shimano Claris RD-R2000 / SS cage
Front Derailleur
Shimano Claris FD-R2000
Shift Levers
Shimano Claris ST-R2000 2x8 speed
Cassette
Shimano CS-HG41-8 / 11-32T
Crank
Shimano FC-RS200 / 50-34T / XS-S, 170mm / M-XL, 175mm
Bottom Bracket
Shimano BB-UN26 68-110mm
Chain
KMC x8
Pedals
NW-91K w/ Toeclip
Wheels
Front Hub
KT 5P5F/G5ER 28h / front / rear
Rear Hub
KT 5P5F/G5ER 28h / front / rear
Rims
Jalco MRX-24 / 28h
Spokes
Steel 14g
Tires
CST Compressor 700x25c 60TPI
Brakes
Brakes
Tektro R-315 57mm drop
Brake Levers
Shimano Claris ST-R2000
Cockpit
Stem
Genesis AS-007 / + - 7deg / XXS-XS, 80mm / S-M, 90mm
Handlebar
Genesis alloy / 125mm drop x 70mm reach / XXS-XS, 360mm / S-M, 380mm
Headset
Prestine PT-F23 1-1/8" - 1-1/2" tapered
Seat
Saddle
Genesis Road Comfort WS
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.44 mm | 1.47 mm | 1.49 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 265 mm | 265 mm |
| Front Center | 584 mm | 588 mm | 596 mm | 604 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 61 mm | 61 mm | 61 mm | 58 mm |
| Stack | 526 mm | 540 mm | 558 mm | 574 mm |
| Reach | 373 mm | 374 mm | 379 mm | 384 mm |
| Top Tube Length | 514 mm | 529 mm | 545 mm | 557 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73.25 ° |
| Seat Tube Length | 450 mm | 475 mm | 495 mm | 510 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 72 ° |
| Head Tube Length | 125 mm | 140 mm | 160 mm | 176 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheelbase | 987 mm | 991 mm | 1000 mm | 1008 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 71 mm | 71 mm |
| Standover Height | 734 mm | 757 mm | 780 mm | 802 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 145 cm | 157 cm | 165 cm | 174 cm |
| Rider Max Height | 159 cm | 168 cm | 176 cm | 183 cm |
About this model
Delta 10 W completes the Genesis Delta model. Genesis released 15 bikes variations of this model so far. You can get a glimpse at all models from 2018, by clicking on this link.
Model range prices
Genesis Delta 24 2018 is the most economical model, with a starting price of 522$. Genesis Delta 20 W 2018 on the other hand costs 882$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Endurance bikes average price
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, even if your budget is less than the average, you might still be able to get a top-quality Endurance bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Genesis released this model in 2018, its price was 699$. Comparing this to the average Endurance bike price, we see that the price is 235.62% smaller.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The wheels on Delta 10 W are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Genesis Delta 10 W is equipped with Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Delta 10 W comes in 4 sizes, that range from 145 cm – 183 cm (4.76 ft – 6 ft). In conclusion, you won’t have a problem finding one that suits you.
