Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 725 Heat-Treated Chromoly
Suspension Fork
Carbon Road Disc w/ 1-1/2" - 1-1/8" Tapered Steerer w/ 12mm TA
Drivetrain
Rear Derailleur
Shimano 105 RD-5800 / SS cage
Front Derailleur
Shimano 105 FD-5801
Shift Levers
Shimano ST-RS505 / 2x11 speed
Cassette
Shimano CS-5800-11 / 11-28T
Crank
Shimano 105 FC-5800 / 52-36T / XS, 170mm / S-M, 172.5mm / L-XL, 175mm
Bottom Bracket
Shimano BB-5800
Chain
KMC x11
Wheels
Front Hub
Formula RX-812/RX-300 28h / front 12mm TA / rear 12mm TA / 6-bolt
Rear Hub
Formula RX-812/RX-300 28h / front 12mm TA / rear 12mm TA / 6-bolt
Rims
Genesis SR220 / 28h
Spokes
Stainless steel 14g
Tires
Clement Strada LGG 700x28c 60TPI
Brakes
Brakes
Shimano BR-RS505 hydraulic brakes w/160/140mm TR160 rotors
Brake Levers
Shimano ST-RS505
Cockpit
Stem
Genesis Code 7 / -7deg / XS, 90mm / S-M, 100mm / L-XL, 110mm
Handlebar
Genesis AL-194 / 125mm drop x 80mm reach / XS, 400mm / S-M, 420mm / L-XL, 440mm
Headset
Prestine PT-1806-616 1-1/8" - 1-1/2" tapered
Seat
Saddle
Genesis Road Comfort
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.5 mm | 1.52 mm | 1.53 mm | 1.54 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 581 mm | 591 mm | 594 mm | 609 mm | 625 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 69 mm | 66 mm | 57 mm | 57 mm | 57 mm |
| Stack | 537 mm | 551 mm | 576 mm | 591 mm | 610 mm |
| Reach | 357 mm | 367 mm | 378 mm | 387 mm | 397 mm |
| Top Tube Length | 514 mm | 532 mm | 551 mm | 570 mm | 592 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 530 mm | 550 mm | 580 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 73 ° | 72 ° | 72 ° |
| Head Tube Length | 105 mm | 120 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 982 mm | 992 mm | 995 mm | 1011 mm | 1027 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 741 mm | 765 mm | 807 mm | 818 mm | 891 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Equilibrium Disc 20 belongs to the Genesis Equilibrium model. Genesis released 29 bikes variations of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Genesis Equilibrium 2018 is the most affordable bike of this model and has a price of 1702$. On the other hand, Genesis Equilibrium Disc 20 2018, is the most expensive and costs 2432$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Endurance bikes average price
Our math shows that the average cost of a dependable Endurance bike is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Genesis Equilibrium Disc 20 price was 2432$. Doing a quick comparison, we notice that Equilibrium Disc 20 price is 3.67% more expensive than the average cost of an Endurance bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When leaving the production line, the Equilibrium Disc 20 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Genesis Equilibrium Disc 20 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Equilibrium Disc 20 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
