Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b -
Groupset Rival, Rival 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Genesis MjÖlnir Seamless Double-Butted Cromoly
Suspension Fork
Carbon Road Plus w/ 1-1/2"-1-1/8" Tapered Alloy Steerer
Drivetrain
Rear Derailleur
SRAM Rival 1x / Long cage
Shift Levers
SRAM Rival / 1x11 speed
Cassette
SRAM PG1130 / 11-42T
Crank
SRAM Rival 1 XSYNC / 42T / XS, 170mm / S-M, 172.5mm / L-XL, 175mm
Bottom Bracket
SRAM GXP 68mm
Chain
KMC x11
Wheels
Front Hub
Formula RX-812F /RX-300R 32h / front / rear / 6-bolt
Rear Hub
Formula RX-812F /RX-300R 32h / front / rear / 6-bolt
Rims
Jalco XM420 / 32h
Spokes
Stainless steel 14g
Tires
WTB Byway 650x47c w/skinwall
Brakes
Brakes
SRAM Rival hydraulic brakes w/160mm SRAM Centerline rotors
Brake Levers
SRAM Rival 1x Hydraulic
Cockpit
Stem
Genesis AS-007 / + - 7deg / 100mm
Handlebar
Genesis X-Race Pro / 16deg Flare / XS, 400mm / S-M, 420mm / L-XL, 440mm
Headset
Prestine F-17-A 1-1/8" - 1-1/2" tapered
Seat
Saddle
Genesis Road Comfort
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.53 mm | 0.87 mm | 1.55 mm | 1.56 mm |
| Front Center | 596 mm | 612 mm | 628 mm | 645 mm | 660 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Stack | 558 mm | 577 mm | 596 mm | 615 mm | 633 mm |
| Reach | 367 mm | 377 mm | 687 mm | 397 mm | 407 mm |
| Top Tube Length | 537 mm | 553 mm | 569 mm | 585 mm | 600 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 550 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 125 mm | 145 mm | 165 mm | 185 mm | 205 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1014 mm | 1031 mm | 1047 mm | 1064 mm | 1079 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 758 mm | 781 mm | 803 mm | 822 mm | 845 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Fugio 30 completes the Genesis Fugio model. Genesis released 21 bikes variations of this model so far. You can easily view all of the Genesis Fugio bikes models from 2018, here.
Model range prices
Genesis Fugio 20 2018 is the most economical model, with a starting price of 1884$. Genesis Fugio 30 2018 on the other hand costs 2675$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Gravel bikes average price
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2018 for 2675$. Comparing the average cost of a Gravel bike to this one, you will see that Fugio 30 price is 8.65% higher.
Fugio 30 components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on Fugio 30 are the aluminum type. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Nothing is more important on a bike than its ability to brake properly. Genesis Fugio 30 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
