Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b -
Groupset GRX 800 -
Suspension Rigid -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Steel
Drivetrain
Rear Derailleur
Shimano GRX RD-RX812 11 Speed
Shift Levers
Shimano GRX ST-RX810 11 Speed
Cassette
Shimano CS-M8000 11-42T
Bottom Bracket
Shimano SM-BBR60
Chain
KMC X11
Wheels
Front Hub
Formula Front - CL-712 / Rear RXC-142A
Rear Hub
Formula Front - CL-712 / Rear RXC-142A
Rims
WTB ST I25 TCS 2.0
Spokes
Steel 14 g
Tires
WTB Venture 650 x 47c
Brakes
Brakes
Shimano GRX BR-RX810 Hydraulic Disc
Brake Levers
Shimano GRX ST-RX810 11 Speed
Cockpit
Stem
Genesis Alloy 31.8mm -6 deg 100 mm
Headset
F17A Taper 1 1/8 inch - 1 1/5 inch
Seat
Saddle
Genesis
Seatpost
X-Fusion Manic Gravel 50 mm Drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.53 mm | 1.54 mm | 1.55 mm | 1.56 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Stack | 558 mm | 577 mm | 596 mm | 615 mm | 633 mm |
| Reach | 367 mm | 377 mm | 387 mm | 397 mm | 407 mm |
| Top Tube Length | 537 mm | 553 mm | 569 mm | 585 mm | 600 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 550 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 125 mm | 145 mm | 165 mm | 185 mm | 205 mm |
| Wheelbase | 1014 mm | 1031 mm | 1047 mm | 1064 mm | 1079 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 758 mm | 781 mm | 803 mm | 822 mm | 845 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Fugio 30 belongs to the Genesis Fugio model. 21 bikes variations carry this model name so far. You can easily view all of the Genesis Fugio bikes models from 2021, here.
Model range prices
Genesis Fugio 10 2021 is the cheapest bike model and costs 2067$. Genesis Fugio 30 2021 is the most expensive one and costs 3648$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Genesis Fugio 30 price was 3648$. Doing a quick comparison, we notice that Fugio 30 price is 48.17% higher than the average cost of a Gravel bike.
Fugio 30 components
Wheels size
As for the wheels, Genesis Fugio 30 2021, has a aluminum model. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Fugio 30 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
