Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Sora, Shimano -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Genesis MjÖlnir Seamless Double-Butted Cromoly
Suspension Fork
Cr-Mo Unicrown Disc
Drivetrain
Rear Derailleur
Shimano Sora RD-R3000 / GS cage
Front Derailleur
Shimano Sora FD-R3030
Shift Levers
Shimano Sora ST-R3030 / 3x9 speed
Cassette
Shimano CS-HG300-9 / 11-32T
Crank
Shimano FC-R453 / 50-39-30T / XS, 165mm / S, 170mm / M-XL, 175mm
Bottom Bracket
Shimano BB-ES300 68-121mm
Chain
KMC x9
Pedals
NW-99K w/ Toeclip
Wheels
Front Hub
KT K08F/K08R 36h / front / rear / 6-bolt
Rear Hub
KT K08F/K08R 36h / front / rear / 6-bolt
Rims
Jalco DD24 / 36h
Spokes
Stainless steel 14g
Tires
Schwalbe Marathon Mondial 700x35c
Brakes
Brakes
Promax DSK-717 disc brakes w/ 160mm rotors
Brake Levers
Shimano Sora ST-R3030
Cockpit
Stem
Genesis AS-027 / + - 7deg / 100mm
Handlebar
Genesis X-Race Pro / 16deg Flare / XS, 400mm / S-M, 420mm / L-XL, 440mm
Headset
Prestine PT-1606 1-1/8" semi cartridge
Seat
Saddle
Genesis Road Comfort
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.55 mm | 1.52 mm | 1.49 mm | 1.47 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm | 274 mm | 274 mm |
| Front Center | 597 mm | 612 mm | 639 mm | 664 mm | 691 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Trail | 61 mm | 61 mm | 61 mm | 61 mm | 61 mm |
| Stack | 565 mm | 579 mm | 598 mm | 617 mm | 636 mm |
| Reach | 364 mm | 374 mm | 394 mm | 414 mm | 434 mm |
| Top Tube Length | 532 mm | 546 mm | 577 mm | 603 mm | 635 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 530 mm | 570 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 125 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 454 mm | 454 mm | 454 mm | 454 mm | 454 mm |
| Wheelbase | 1040 mm | 1055 mm | 1082 mm | 1108 mm | 1135 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 757 mm | 777 mm | 798 mm | 806 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Tour De Fer 10 is part of the Genesis Tour model. 25 bikes variations carry this model name so far. Take a sneak peek at all Genesis Tour bikes models from 2018, by clicking here.
Model range prices
Genesis Tour De Fer 10 2018 is the most economical model, with a starting price of 1458$. Genesis Tour De Fer 30 2018 on the other hand costs 2188$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Genesis released this model in 2018, its price was 1458$. Comparing the average cost of a Gravel bike to this one, you will see that Tour De Fer 10 price is 68.86% lower.
Tour De Fer 10 components
Fork material
Tour De Fer 10 has a steel fork, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
When it comes to wheels, the Tour De Fer 10 bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Tour De Fer 10 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Tour De Fer 10 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
