Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Steel
Suspension Fork
Genesis Full Chromoly
Drivetrain
Rear Derailleur
Shimano Tiagra RD-4700-GS Medium Cage
Front Derailleur
Shimano Tiagra FD-4703
Shift Levers
Shimano Tiagra ST-4700 3 x 10 Speed
Cassette
Shimano CS-HG500-10 11-32T
Bottom Bracket
Shimano BB-ES300
Chain
KMC X10
Pedals
NW-91K With Cage
Wheels
Front Hub
Shimano Front - DH-UR700-3D / Rear FH-M6000
Rear Hub
Shimano Front - DH-UR700-3D / Rear FH-M6000
Rims
Sun Ringle Rhyno Lite
Spokes
Steel 14 g
Tires
Schwalbe Marathon
Brakes
Brakes
TRP Spyre-C Mechanical Disc
Brake Levers
Shimano Tiagra ST-4700 3 x 10 Speed
Cockpit
Stem
Genesis Alloy 31.8mm -6 deg 100 mm
Headset
PT-1770 EC34 Upper / EC34 Lower
Seat
Saddle
Genesis
Seatpost
Genesis Alloy 27.2 XS/S/M = 350 mm L/XL = 400 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.55 mm | 1.52 mm | 1.49 mm | 1.47 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 261 mm | 261 mm | 261 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Stack | 565 mm | 579 mm | 598 mm | 617 mm | 636 mm |
| Reach | 364 mm | 374 mm | 394 mm | 414 mm | 434 mm |
| Top Tube Length | 532 mm | 546 mm | 577 mm | 603 mm | 635 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 530 mm | 570 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 125 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Wheelbase | 1040 mm | 1055 mm | 1082 mm | 1108 mm | 1135 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 757 mm | 777 mm | 798 mm | 806 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Tour De Fer 30 completes the Genesis Tour model. Genesis launched 25 bikes of this model so far. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Genesis Tour De Fer 10 2019 is the most affordable bike of this model and has a price of 1458$. On the other hand, Genesis Tour De Fer 30 2019, is the most expensive and costs 2188$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Touring bikes
If you want to purchase a solid Touring bike, it is important to know that the average cost is 1007$. However, you could also get a good Touring bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2019 for 2188$. Doing a quick comparison, we notice that Tour De Fer 30 price is 117.28% more expensive than the average cost of a Touring bike.
Tour De Fer 30 components
Fork material
Tour De Fer 30 has a steel fork, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
When it comes to wheels, the Tour De Fer 30 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Genesis Tour De Fer 30 has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
