Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Groupset Deore, microSHIFT -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Genesis MjÖlnir Seamless Double-Butted Cromoly
Suspension Fork
Cr-Mo Unicrown Disc
Drivetrain
Rear Derailleur
Shimano Deore RD-M6000 / SGS cage
Front Derailleur
Shimano Deore FD-M618
Shift Levers
Microshift BS-M10 2/3x10 speed bar end
Cassette
Shimano CS-HG50-10 / 11-36T
Crank
Samox AF12 / 40-28T / S, 170mm / M-XL, 175mm
Bottom Bracket
Samox BB-E24
Chain
KMC x10
Wheels
Front Hub
KT K-68F/68R 32h / front / rear / 6-bolt
Rear Hub
KT K-68F/68R 32h / front / rear / 6-bolt
Rims
Jalco XCD18 / 32h
Spokes
Steel 14g
Tires
WTB Nano 29x2.1"
Brakes
Brakes
TRP Spyre-C 2-piston mechanical disc brake w/160mm TR160 rotors
Brake Levers
Promax BL-253
Cockpit
Stem
Genesis D345G / +15deg / 100mm
Handlebar
Genesis X-Race Aero / 16deg Flare / S, 420mm / M, 440mm / L-XL, 460mm
Headset
Prestine PT-1770 1-1/8" semi cartridge
Seat
Saddle
Genesis Road Comfort
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.67 mm | 1.63 mm | 1.59 mm | 1.58 mm |
| Front Center | 596 mm | 621 mm | 648 mm | 669 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm |
| Trail | 67 mm | 67 mm | 67 mm | 67 mm |
| Stack | 585 mm | 604 mm | 623 mm | 642 mm |
| Reach | 351 mm | 371 mm | 391 mm | 406 mm |
| Top Tube Length | 537 mm | 562 mm | 589 mm | 610 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 430 mm | 460 mm | 490 mm | 520 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 120 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1026 mm | 1052 mm | 1079 mm | 1100 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 73 mm | 73 mm |
| Standover Height | 771 mm | 792 mm | 826 mm | 835 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Vagabond completes the Genesis Vagabond model. Genesis launched 12 bikes of this model so far. You can get a glimpse at all models from 2018, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Genesis released this model in 2018, its price was 1337$. Doing a quick comparison, we notice that Vagabond price is 84.14% smaller than the average cost of a Gravel bike.
Overview of components
Fork material
The fork is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
When leaving the production line, the Vagabond model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Genesis Vagabond has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
