Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Groupset Apex 1 -
Suspension Rigid -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Steel
Drivetrain
Rear Derailleur
SRAM Apex 1 Long Cage 11 Speed
Shift Levers
SRAM APEX 1 11spd
Cassette
SRAM PG1130 11-42T
Bottom Bracket
SRAM GXP XR 73mm
Chain
KMC X11
Wheels
Front Hub
Formula Front - CL-712 / Rear RXC-142A
Rear Hub
Formula Front - CL-712 / Rear RXC-142A
Rims
WTB ST i25 TCS 2.0
Spokes
Steel 14 g
Tires
Kenda Saber Pro 29 x 2.1 Tubeless Ready
Brakes
Brakes
Tektro Spyre-C Mechanical Disc
Brake Levers
SRAM Apex 1 11 Speed
Cockpit
Stem
Genesis Alloy -/+17deg 100 mm
Headset
PT-1770 EC34 Upper / EC34 Lower
Seat
Saddle
Genesis
Seatpost
Genesis Alloy 27.2 x 400 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.67 mm | 1.63 mm | 1.59 mm | 1.58 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm |
| Stack | 585 mm | 604 mm | 623 mm | 642 mm |
| Reach | 351 mm | 371 mm | 391 mm | 406 mm |
| Top Tube Length | 537 mm | 562 mm | 589 mm | 610 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 430 mm | 460 mm | 490 mm | 520 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 120 mm | 140 mm | 160 mm | 180 mm |
| Wheelbase | 1026 mm | 1052 mm | 1079 mm | 1100 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 73 mm | 73 mm |
| Standover Height | 771 mm | 792 mm | 826 mm | 835 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Vagabond is part of the Genesis Vagabond model. Genesis launched 12 bikes of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2020 for 1580$. Comparing this to the average Gravel bike price, we see that the price is 55.82% lower.
Overview of components
Wheels
When it comes to wheels, the Vagabond bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The Vagabond has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Genesis Vagabond bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
