Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Groupset Apex 1 -
Suspension Rigid -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Steel
Drivetrain
Rear Derailleur
SRAM Apex 1 Long Cage 11 Speed
Shift Levers
SRAM APEX 1 11spd
Cassette
SRAM PG1130 11-42T
Bottom Bracket
SRAM GXP XR 73mm
Chain
KMC X11
Wheels
Front Hub
Formula Front - CL-712 / Rear RXC-142A
Rear Hub
Formula Front - CL-712 / Rear RXC-142A
Rims
WTB ST i25 TCS 2.0
Spokes
Steel 14 g
Tires
Kenda Saber Pro 29 x 2.1 Tubeless Ready
Brakes
Brakes
Tektro Spyre-C Mechanical Disc
Brake Levers
SRAM Apex 1 11 Speed
Cockpit
Stem
Genesis Alloy -/+17deg 100 mm
Headset
PT-1770 EC34 Upper / EC34 Lower
Seat
Saddle
Genesis
Seatpost
Genesis Alloy 27.2 x 400 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.67 mm | 1.63 mm | 1.59 mm | 1.58 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm |
| Stack | 585 mm | 604 mm | 623 mm | 642 mm |
| Reach | 351 mm | 371 mm | 391 mm | 406 mm |
| Top Tube Length | 537 mm | 562 mm | 589 mm | 610 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 430 mm | 460 mm | 490 mm | 520 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 120 mm | 140 mm | 160 mm | 180 mm |
| Wheelbase | 1026 mm | 1052 mm | 1079 mm | 1100 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 73 mm | 73 mm |
| Standover Height | 771 mm | 792 mm | 826 mm | 835 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Vagabond is part of the Genesis Vagabond model. There are 12 bikes that carry this model name. Take a sneak peek at all Genesis Vagabond bikes models from 2021, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Genesis Vagabond price was 2067$. If we compare this with the average Gravel bike cost we notice that the price is 19.11% smaller.
Vagabond components
Wheels
When leaving the production line, the Vagabond model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. Genesis Vagabond has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Vagabond comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
