Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Steel -
Wheels 29" -
Suspension Rigid
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Steel
Cockpit
Headset
PT-1770 EC34 Upper / EC34 Lower
Seat
Seatpost
27.2 mm Not Included
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.67 mm | 1.63 mm | 1.59 mm | 1.58 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm |
| Stack | 585 mm | 604 mm | 623 mm | 642 mm |
| Reach | 351 mm | 371 mm | 391 mm | 406 mm |
| Top Tube Length | 537 mm | 562 mm | 589 mm | 610 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 430 mm | 460 mm | 490 mm | 520 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 120 mm | 140 mm | 160 mm | 180 mm |
| Wheelbase | 1026 mm | 1052 mm | 1079 mm | 1100 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 73 mm | 73 mm |
| Standover Height | 771 mm | 792 mm | 826 mm | 835 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Vagabond Frameset is part of the Genesis Vagabond model. 12 frames variations carry this model name so far. Take a sneak peek at all Genesis Vagabond frames models from 2022, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Gravel frames
According to our math, the average price for a trustworthy Gravel frame is 1505$. However, even though the average price of a Gravel frame is lower, you might still be able to get a top-quality frame. In conclusion, always check frame reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Genesis Vagabond Frameset price was 972$. In conclusion, this frame price is 54.84% smaller than the price of the average Gravel frame.
Overview of components
Sizes
This frame is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
