Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 180mm -
Travel Rear 155mm -
Fork RockShox Lyrik
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Lyrik RC2
Rear Shock
EXT Storia LOK, 2-way lockout, 155mm travel: 216mm x 63mm, 175mm travel: 222mm x 70mm
Drivetrain
Rear Derailleur
Shimano Deore XT M8000, 11-speed, SHADOW RD, GS cage
Front Derailleur
None
Shift Levers
Shimano Deore XT M8000, 11-speed
Cassette
Shimano Deore XT M8000, 11-speed, 11-46 tooth
Crank
Hope Tech, 170mm length
Bottom Bracket
Hope Tech, 83mm English/BSA threaded
Chain
Shimano Deore XT M8000, 11-speed
Pedals
None
Wheels
Front Hub
Hope Tech Pro4, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rear Hub
Hope Tech Pro4, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rims
Hope Tech Enduro
Spokes
Hope Tech wheelset
Tires
Front: Maxxis Minion DHF, 2.5", Rear: Maxxis Minion DHR II, 2.3"
Brakes
Brakes
Hope Tech 3 E4, 200mm front rotor, 183mm rear rotor
Brake Levers
Hope Tech 3 E4
Cockpit
Stem
Hope Tech AM, 0° rise, 35mm bar clamp
Handlebar
Renthal Fatbar, 800mm width, 20mm rise, 35mm clamp diameter
Grips
Renthal Traction, lock-on, Ultratacky compound
Headset
Hope Tech, ZS44 upper, ZS56 lower
Seat
Saddle
WTB Volt
Seatpost
BikeYoke Revive dropper, Drop options: 160mm, 185mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.22 mm | 1.2 mm | 1.17 mm | 1.17 mm |
| Stack | 596 mm | 604 mm | 613 mm | 631 mm |
| Reach | 488 mm | 505 mm | 523 mm | 538 mm |
| Top Tube Length | 625 mm | 644 mm | 664 mm | 683 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 420 mm | 450 mm | 470 mm | 500 mm |
| Head Tube Angle | 62.5 ° | 62.5 ° | 62.5 ° | 62.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 150 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1281 mm | 1303 mm | 1331 mm | 1355 mm |
| Standover Height | 711 mm | 730 mm | 750 mm | 770 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
G16 Shimano XT is part of the Geometron G16 model. GeoMetron launched 3 frames of this model so far. You can easily view all of the Geometron G16 frames models from 2021, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Enduro frames
According to our math, the average price for a trustworthy Enduro frame is 1895$. However, this doesn’t mean that if you spend less money on an Enduro frame, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your frame, always do some components analysis and read reviews.
Overview of components
Fork
The G16 Shimano XT comes factory-installed with the RockShox Lyrik fork. This has a travel range of 180mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the EXT Storia LOK rear shock model, which has a travel of 155mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When leaving the production line, the G16 Shimano XT model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The G16 Shimano XT comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This frame is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the G16 Shimano XT. Therefore, climbing or descending will be a breeze.
