Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 130mm -
Fork SunTour XCR 34
-
Groupset Deore, Shimano -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano BT-E8010 with Shimano EC-E6000 charger -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
SR Suntour XCR 34 LOR Air, Boost
Rear Shock
X-Fusion O2 Pro RL Air
Drivetrain
Rear Derailleur
Shimano Deore RD-M6000 Shadow Plus
Front Derailleur
N/A
Shift Levers
Shimano Deore SL-M6000, 11-speed
Cassette
Shimano CS-HG500-10, 11-42 tooth, 11-speed
Crank
Shimano FC-E8000
Chain
11-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Front: Formula EHL-148S, Boost 15mm x 110mm, Rear: Formula DC-511, Boost 12mm x 110mm
Rear Hub
Front: Formula EHL-148S, Boost 15mm x 110mm, Rear: Formula DC-511, Boost 12mm x 110mm
Rims
Rodi Tryp, 25mm width, 32 hole
Spokes
Rodi Tryp
Tires
Schwalbe Nobby Nic Performance Addix, 2.25"
Brakes
Brakes
Magura MT Thirty 2 with 203mm rotors, 4/2 pistons
Brake Levers
Magura MT Thirty 2
Cockpit
Stem
Ghost MTB, 55mm length, 35mm clamp
Handlebar
Ghost Low Rizer MTB, 760mm width, 15mm rise, 35mm diameter
Headset
16012, 44mm top / 56mm bottom
Seat
Saddle
Selle Italia X-Base
Seatpost
Ghost Light DC 1, 400mm length
Motor & Battery
Motor
Shimano DU-E8000
Battery
Shimano BT-E8010 with Shimano EC-E6000 charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.76 mm | 1.71 mm | 1.68 mm | 1.64 mm |
| Bottom Bracket Height | 354 mm | 354 mm | 354 mm | 354 mm |
| Front Center | 731 mm | 758 mm | 787 mm | 815 mm |
| Rake | -11 mm | -10 mm | -9 mm | -9 mm |
| Trail | 179 mm | 178 mm | 177 mm | 177 mm |
| Stack | 751 mm | 765 mm | 783 mm | 801 mm |
| Reach | 427 mm | 447 mm | 467 mm | 487 mm |
| Top Tube Length | 580 mm | 604 mm | 629 mm | 654 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 390 mm | 430 mm | 460 mm | 500 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 160 mm |
| Chainstay Length | 462 mm | 462 mm | 462 mm | 462 mm |
| Wheelbase | 1192 mm | 1219 mm | 1248 mm | 1276 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 751 mm | 765 mm | 783 mm | 801 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Hybride Kato FS S3.9 AL belongs to the Ghost E Hybride model. 20 e-bikes variations carry this model name so far. Take a sneak peek at all Ghost E Hybride e-bikes models from 2018, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail e-bikes average price
Our math shows that the average cost of a dependable Trail e-bike is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Hybride Kato FS S3.9 AL components
Fork
This e-bike has the SunTour XCR 34 fork installed. The fork’s travel is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The shock that’s installed on this e-bike is X-Fusion O2 Pro RL Air, with a travel distance of 130mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The wheels on Hybride Kato FS S3.9 AL are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The Hybride Kato FS S3.9 AL has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Ghost Hybride Kato FS S3.9 AL e-bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
