Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" / 27.5" -
Travel Front 160mm -
Travel Rear 140mm -
Fork RockShox Yari RC
-
Groupset XT, SLX -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano BT-E8010 with Shimano EC-E6000 charger -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
RockShox Yari RC Dual Position Air
Rear Shock
Cane Creek DB Inline Coil CS
Drivetrain
Rear Derailleur
Shimano XT RD-M8000 Shadow Plus
Front Derailleur
N/A
Shift Levers
Shimano SLX SL-M7000, 11-speed
Cassette
Sunrace MS8-E, 11-46 tooth, 11-speed
Crank
Ground Fiftyone
Chain
11-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
DT Swiss H 1900 Spline, Boost front and rear
Rear Hub
DT Swiss H 1900 Spline, Boost front and rear
Rims
Front: DT Swiss H 1900 Spline, 30mm width, Rear: DT Swiss H 1900 Spline, 35mm width
Spokes
DT Swiss
Tires
Front: Maxxis Shorty, 29" x 2.5" 3C MaxxTerra EXO, Rear: Maxxis Minion DHR II, 27.5" x 2.8" 3C MaxxTerra EXO
Brakes
Brakes
Magura MT 5 with 203mm rotors, 4 pistons
Brake Levers
Magura MT 5
Cockpit
Stem
Ground Fiftyone Race, 45mm length, 35mm clamp
Handlebar
Ground Fiftyone Race, 780mm width, 35mm rise, 35mm diameter
Grips
Ergon
Headset
16012, 44mm top / 56mm bottom
Seat
Saddle
Ergon SME30
Seatpost
KS Lev Integra, 175mm drop
Motor & Battery
Motor
Shimano DU-E8000
Battery
Shimano BT-E8010 with Shimano EC-E6000 charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.45 mm | 1.38 mm | 1.33 mm |
| Front Center | 732 mm | 755 mm | 799 mm | 836 mm |
| Rake | 47 mm | 47 mm | 46 mm | 46 mm |
| Trail | 118 mm | 118 mm | 119 mm | 119 mm |
| Stack | 623 mm | 632 mm | 651 mm | 670 mm |
| Reach | 418 mm | 437 mm | 473 mm | 502 mm |
| Top Tube Length | 581 mm | 603 mm | 643 mm | 677 mm |
| Seat Tube Angle | 75.2 ° | 75.2 ° | 75.2 ° | 75.2 ° |
| Seat Tube Length | 390 mm | 430 mm | 460 mm | 500 mm |
| Head Tube Angle | 65.6 ° | 65.6 ° | 65.6 ° | 65.6 ° |
| Head Tube Length | 90 mm | 100 mm | 120 mm | 140 mm |
| Chainstay Length | 462 mm | 462 mm | 462 mm | 462 mm |
| Wheelbase | 1193 mm | 1216 mm | 1260 mm | 1297 mm |
| Bottom Bracket Drop | 23 mm | 23 mm | 23 mm | 23 mm |
| Standover Height | 729 mm | 734 mm | 760 mm | 782 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Hybride SL AMR X S 5.7+ LC is a Ghost E Hybride model. There are 20 e-bikes that carry this model name. You can get a glimpse at all models from 2018, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail e-bikes average price
Our math shows that the average cost of a dependable Trail e-bike is 3365$. However, this doesn’t mean that if you spend less money on a Trail e-bike, you couldn’t get a decent one. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Hybride SL AMR X S 5.7+ LC components
Fork
This e-bike has the RockShox Yari RC fork installed. The fork’s travel is 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
Ghost Hybride SL AMR X S 5.7+ LC e-bike has the Cane Creek DB Inline Coil CS model installed, and has a travel of 140mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on Hybride SL AMR X S 5.7+ LC are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Hybride SL AMR X S 5.7+ LC comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Ghost Hybride SL AMR X S 5.7+ LC comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
