Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 130mm -
Fork RST
-
Groupset Deore -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RST Aerial TnL Air
Rear Shock
XFusion O2 Pro RL Air
Drivetrain
Rear Derailleur
Shimano Deore RD-M6000, Shadow Plus, 10-speed
Front Derailleur
Shimano Deore FD-M6020 Side Swing
Shift Levers
Shimano Deore SL-M6000
Cassette
Shimano CS-HG500-10, 11-42 tooth
Crank
Shimano Deore FC-M6000 Hollowtech II
Bottom Bracket
BSA 68mm
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Front: Formula DC 20, QR, Rear: Formula DC 22, QR
Rear Hub
Front: Formula DC 20, QR, Rear: Formula DC 22, QR
Rims
Rodi Excalibur XC, 32 hole
Tires
Continental X-King PureGrip, 27.5" x 2.2"
Brakes
Brakes
Tektro HD-M285, 2-piston calipers, 180mm rotors
Brake Levers
Tektro HD-M285
Cockpit
Stem
Ghost MTB, 31.8mm clamp, 60mm length
Handlebar
Ghost Low Rizer MTB, 760mm width, 31.8mm clamp, 15mm rise
Headset
16012
Seat
Saddle
Selle Italia X-Base
Seatpost
Ghost Light DC 1
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.35 mm | 1.31 mm | 1.29 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Front Center | 684 mm | 711 mm | 736 mm | 752 mm |
| Rake | 44 mm | 45 mm | 44 mm | 44 mm |
| Trail | 89 mm | 88 mm | 89 mm | 89 mm |
| Stack | 590 mm | 600 mm | 609 mm | 618 mm |
| Reach | 421 mm | 443 mm | 465 mm | 478 mm |
| Top Tube Length | 578 mm | 603 mm | 628 mm | 648 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 420 mm | 460 mm | 500 mm | 540 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1117 mm | 1144 mm | 1169 mm | 1185 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm | 15 mm |
| Standover Height | 703 mm | 748 mm | 758 mm | 788 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Kato FS AL 2.7 is part of the Ghost Kato model. There are 96 bikes that carry this model name. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Ghost Kato Kid 4 AL 24 2018 is the most economical model, with a starting price of 466$. Ghost Kato X 6.9 AL 2018 on the other hand costs 1592$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Trail bikes
The average weight for Trail bikes is 12.98 kg (28.62 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
considerably heavier than average, Kato FS AL 2.7 has a weight of 14.9 kg (32.85 lbs). In conclusion, the average Trail bike weighs 14.79% less than Kato FS AL 2.7.
Kato FS AL 2.7 components
Fork
The Kato FS AL 2.7 comes factory-installed with the RST fork. This has a travel range of 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
From the factory, it comes with the XFusion O2 Pro RL Air rear shock model, which has a travel of 130mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
When leaving the production line, the Kato FS AL 2.7 model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Kato FS AL 2.7 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
