Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 130mm -
Fork SunTour AION
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
SR Suntour Aion LO-R
Rear Shock
XFusion O2 Pro RL Air
Drivetrain
Rear Derailleur
Shimano XT RD-M8000, Shadow Plus, 11-speed
Front Derailleur
Shimano SLX FD-M7020 Side Swing
Shift Levers
Shimano SLX SL-M7000
Cassette
Shimano SLX CS-M7000, 11-42 tooth
Crank
Shimano FC-MT600
Bottom Bracket
BSA 68mm
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Front: Shimano Deore HB-M6010, 15x100mm, Rear: Shimano Deore FH-M6000, QR
Rear Hub
Front: Shimano Deore HB-M6010, 15x100mm, Rear: Shimano Deore FH-M6000, QR
Rims
Rodi Excalibur XC, 32 hole
Tires
Continental X-King PureGrip, 27.5" x 2.2"
Brakes
Brakes
Shimano 506, 2-piston calipers, 180mm rotors
Brake Levers
Shimano 506
Cockpit
Stem
Ghost MTB, 31.8mm clamp, 60mm length
Handlebar
Ghost Low Rizer MTB, 760mm width, 31.8mm clamp, 15mm rise
Headset
16012
Seat
Saddle
Velo VL-4212
Seatpost
Ghost Light DC 1
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.46 mm | 1.4 mm | 1.33 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 632 mm | 662 mm | 693 mm | 728 mm |
| Rake | 39 mm | 39 mm | 39 mm | 43 mm |
| Trail | 95 mm | 95 mm | 95 mm | 90 mm |
| Stack | 583 mm | 583 mm | 593 mm | 602 mm |
| Reach | 368 mm | 398 mm | 425 mm | 452 mm |
| Top Tube Length | 527 mm | 557 mm | 587 mm | 616 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 380 mm | 420 mm | 460 mm | 500 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1059 mm | 1089 mm | 1120 mm | 1155 mm |
| Bottom Bracket Drop | 14 mm | 14 mm | 14 mm | 14 mm |
| Standover Height | 692 mm | 706 mm | 737 mm | 749 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
Model Overview
Lanao FS AL 3.7 is a Ghost Lanao model. There are 65 bikes that carry this model name. Take a sneak peek at all Ghost Lanao bikes models from 2018, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Lanao FS AL 3.7 components
Fork
The SunTour AION is included from the factory. It has a travel distance of 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The shock that’s installed on this bike is XFusion O2 Pro RL Air, with a travel distance of 130mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The Lanao FS AL 3.7 2018 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Ghost Lanao FS AL 3.7 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Lanao FS AL 3.7 comes in 4 sizes, that range from 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, you can easily find one that suits you.
