Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 130mm -
Fork Fox Performance Float 32
-
Groupset XT -
Suspension Full -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX 32 Float Performance
Rear Shock
FOX Float DPS Performance Air
Drivetrain
Rear Derailleur
Shimano XT RD-M8000, Shadow Plus, 11-speed
Front Derailleur
Shimano XT FD-M8020 Side Swing
Shift Levers
Shimano XT SL-M8000
Cassette
Shimano SLX CS-M7000, 11-42 tooth
Crank
Shimano XT FC-M8000 Hollowtech II
Bottom Bracket
BSA 68mm
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Front: Shimano Deore HB-M6010, 15x100mm, Rear: Shimano Deore FH-M6000, QR
Rear Hub
Front: Shimano Deore HB-M6010, 15x100mm, Rear: Shimano Deore FH-M6000, QR
Rims
Rodi Blackrock, 32 hole
Tires
Continental X-King PureGrip, 27.5" x 2.2"
Brakes
Brakes
Shimano XT BR-M8000, 2-piston calipers, 180mm rotors
Brake Levers
Shimano XT
Cockpit
Stem
Ghost MTB, 31.8mm clamp, 60mm length
Handlebar
Ghost Low Rizer MTB, 760mm width, 31.8mm clamp, 15mm rise
Headset
16012
Seat
Saddle
Velo VL-4212
Seatpost
Ghost Light DC 1
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.46 mm | 1.4 mm | 1.33 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 632 mm | 662 mm | 693 mm | 728 mm |
| Rake | 39 mm | 39 mm | 39 mm | 43 mm |
| Trail | 95 mm | 95 mm | 95 mm | 90 mm |
| Stack | 583 mm | 583 mm | 593 mm | 602 mm |
| Reach | 368 mm | 398 mm | 425 mm | 452 mm |
| Top Tube Length | 527 mm | 557 mm | 587 mm | 616 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 380 mm | 420 mm | 460 mm | 500 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1059 mm | 1089 mm | 1120 mm | 1155 mm |
| Bottom Bracket Drop | 14 mm | 14 mm | 14 mm | 14 mm |
| Standover Height | 692 mm | 706 mm | 737 mm | 749 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
Lanao FS AL 5.7 completes the Ghost Lanao model. 65 bikes variations carry this model name so far. Take a sneak peek at all Ghost Lanao bikes models from 2018, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Lanao FS AL 5.7 components
Fork
The Fox Performance Float 32 is included from the factory. It has a travel distance of 130mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is FOX Float DPS Performance Air, with a travel distance of 130mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The wheels on Lanao FS AL 5.7 are the 27.5″ aluminum type. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Lanao FS AL 5.7 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Lanao FS AL 5.7 comes in 4 sizes, that range from 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, finding one for you shouldn’t be a problem.
