Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Alivio, Acera -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
161cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
XL
185cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SQUARE Cross AL
Suspension Fork
SR Suntour SF14 NEX DS-700C 63 mm
Drivetrain
Rear Derailleur
Shimano Alivio RD-M3100 9-S
Front Derailleur
Shimano Acera FD-T3000
Cassette
Shimano CS-HG400-9 11-34
Crank
Shimano FC-T3010 44-32-22
Bottom Bracket
Prestine PT-6621
Chain
KMC X9
Pedals
FPD NW-499
Wheels
Rims
Rodi Excalibur XC19
Tires
Front: Schwalbe Smart Sam Performance 47-622, Rear: Schwalbe Smart Sam Performance 47-622
Brakes
Brakes
Shimano BR-MT200 160 mm Disc
Brake Levers
Shimano BL-MT200
Cockpit
Stem
GHOST SQUARE Dia. 31.8 mm
Handlebar
GHOST Low Rizer SQUARE 680 mm Rise 25 mm Dia. 31.8 mm
Grips
Velo Grip
Seat
Saddle
Justek 3050 HRN
Seatpost
GHOST SP DC1 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.63 mm | 1.66 mm | 1.69 mm |
| Stack | 638 mm | 643 mm | 666 mm | 685 mm |
| Reach | 393 mm | 395 mm | 402 mm | 405 mm |
| Top Tube Length | 582 mm | 597 mm | 612 mm | 627 mm |
| Seat Tube Angle | 73.5 ° | 72.5 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 470 mm | 520 mm | 570 mm | 620 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° | 71 ° |
| Head Tube Length | 160 mm | 165 mm | 185 mm | 205 mm |
| Wheelbase | 1107 mm | 1110 mm | 1114 mm | 1123 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 737 mm | 772 mm | 817 mm | 857 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 161 cm | 168 cm | 176 cm | 185 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm | 194 cm |
About this model
Square Cross Base is a Ghost Square model. 79 bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Ghost Square Cross Base AL W 2023 is the most economical model, with a starting price of 742$. Ghost Square Cross Essential 2023 on the other hand costs 1167$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Hybrid bikes average price
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Ghost released this model in 2023, its price was 742$. Doing a quick comparison, we notice that Square Cross Base price is 32.03% more expensive than the average cost of a Hybrid bike.
Overview of components
Fork
The fork installed on this bike is the Suntour NEX model. The travel on this model is 63mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
As for the wheels, Ghost Square Cross Base 2023, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Square Cross Base comes in 4 sizes, that range from 161 cm – 194 cm (5.28 ft – 6.36 ft). In conclusion, finding one for you shouldn’t be a problem.
