Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Acera, Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 170cm
MD
167cm - 178cm
LG
175cm - 186cm
XL
183cm - 203cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SQUARE TREKKING AL
Suspension Fork
SR Suntour NEX DS 63 mm
Drivetrain
Rear Derailleur
Shimano Acera RD-M3020 8-S
Cassette
Shimano CS-HG31 11-34
Crank
Shimano FC-TY301 48-38-28
Bottom Bracket
Thun Jive 3.0 FS
Chain
KMC Z51
Pedals
FPD NW-499
Wheels
Front Hub
Shimano DH-3D37-QR Hyb Dynamo
Rear Hub
Shimano FH-TX505 QR 135 mm
Rims
Rodi Excalibur XC19
Tires
Front: Schwalbe Energizer Activ Plus 37-622, Rear: Schwalbe Energizer Activ Plus 37-622
Brakes
Brakes
Shimano BR-MT200 160 mm Disc
Brake Levers
Shimano BL-MT200
Cockpit
Stem
Ghost Dia. 31.8 mm
Handlebar
GHOST Dia. 31.8 mm 680 mm
Grips
Velo VLG-1752D2
Headset
Strummer semi-integrated
Seat
Saddle
Justek 3050 HRN
Seatpost
GHOST SP DC1 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.63 mm | 1.66 mm | 1.69 mm |
| Front Center | 657 mm | 660 mm | 664 mm | 673 mm |
| Rake | 50 mm | 49 mm | 50 mm | 50 mm |
| Trail | 74 mm | 75 mm | 67 mm | 67 mm |
| Stack | 638 mm | 643 mm | 666 mm | 685 mm |
| Reach | 393 mm | 395 mm | 402 mm | 405 mm |
| Top Tube Length | 582 mm | 597 mm | 612 mm | 627 mm |
| Seat Tube Angle | 73.5 ° | 72.5 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 470 mm | 520 mm | 570 mm | 620 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° | 71 ° |
| Head Tube Length | 160 mm | 165 mm | 185 mm | 205 mm |
| Chainstay Length | 457 mm | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1107 mm | 1110 mm | 1114 mm | 1123 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 737 mm | 772 mm | 817 mm | 857 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 167 cm | 175 cm | 183 cm |
| Rider Max Height | 170 cm | 178 cm | 186 cm | 203 cm |
Model Overview
Square Trekking is a Ghost Square model. There are 79 bikes that carry this model name. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Ghost Square Cross Base AL W 2023 is the most economical model, with a starting price of 742$. Ghost Square Cross Essential 2023 on the other hand costs 1167$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Hybrid bikes average price
If you want an acceptable Hybrid bike you should know that the average price is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1061$. Comparing this to the average Hybrid bike price, we see that the price is 88.79% higher.
Overview of components
Fork
The Suntour NEX is included from the factory. It has a travel distance of 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The wheels on Square Trekking are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Ghost Square Trekking is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Square Trekking comes in 4 sizes, that range from 157 cm – 203 cm (5.15 ft – 6.66 ft). In short, it won’t be difficult to find the right one for you.
