Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XXS
152cm - 158cm
XS
156cm - 163cm
SM
161cm - 171cm
SM
161cm - 171cm
MD
169cm - 176cm
LG
174cm - 186cm
XL
184cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminum
Suspension Fork
alloy suspension fork
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano RD-TX800
Front Derailleur
Shimano FD-M313
Shift Levers
Shimano SL-M315, 3x8
Cassette
Shimano HG200, 12x32
Crank
alloy, 170mm, 22/32/42
Bottom Bracket
cartridge
Chain
KMC Z8.3
Pedals
platform
Wheels
Front Hub
Giant alloy, sealed bearing
Rear Hub
Giant alloy, sealed bearing
Rims
Giant alloy
Spokes
stainless, 14g
Tires
Giant Quickcross, 27.5x2.1"
Brakes
Brakes
TKD-143, mechanical [F]160mm, [R]160mm rotors
Brake Levers
TKD-143
Cockpit
Stem
Giant Sport, alloy, 15-degree, 75/90/105mm
Handlebar
flat, alloy, 620/640x31.8mm
Grips
Giant Sole-O
Seat
Saddle
Giant custom
Seatpost
Giant Sport, 350x30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | SM | MD | LG | XL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.42 mm | 1.44 mm | 1.44 mm | 1.46 mm | 1.5 mm | 1.51 mm |
| Front Center | 647 mm | 658 mm | 669 mm | 650 | 661 mm | 684 mm | 706 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 92.5 mm | 92.5 mm | 92.5 mm | 92.5 mm | 92.5 mm | 92.5 mm | 92.5 mm |
| Stack | 557 mm | 566 mm | 580 mm | 582 mm | 596 mm | 629 mm | 652 mm |
| Reach | 391 mm | 399 mm | 404 mm | 404 mm | 409 mm | 419 mm | 432 mm |
| Top Tube Length | 556 mm | 566 mm | 576 mm | 576 mm | 591 mm | 611 mm | 631 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 350 mm | 385 mm | 420 mm | 420 mm | 455 mm | 505 mm | 535 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 105 mm | 120 mm | 95 mm | 110 mm | 145 mm | 170 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1066 mm | 1077 mm | 1088 mm | 1081 mm | 1092 mm | 1115 mm | 1137 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 689 mm | 711 mm | 724 mm | 722 mm | 748 mm | 790 mm | 815 mm |
| Wheels | 26" | 26" | 26" | 650 | 650 | 650 | 650 |
| Rider Min Height | 152 cm | 156 cm | 161 cm | 161 cm | 169 cm | 174 cm | 184 cm |
| Rider Max Height | 158 cm | 163 cm | 171 cm | 171 cm | 176 cm | 186 cm | 193 cm |
Model Overview
ATX 810 is part of the Giant Atx model. There are 16 bikes that carry this model name. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Giant ATX 2022 is the most economical model, with a starting price of 381$. Giant ATX 810 2022 on the other hand costs 458$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Commuter bikes
Our math shows that the average cost of a dependable Commuter bike is 762$. However, you could also get a good Commuter bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 458$. Comparing the average cost of a Commuter bike to this one, you will see that ATX 810 price is 66.38% smaller.
ATX 810 components
Fork material
When it comes to the fork, this bike has an aluminum one, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
The wheels on ATX 810 are the 26″ aluminum type. Being a little smaller, these wheels will fit both small and tall riders. However, they provide less traction than 29″ wheels do.
Brakes
Nothing is more important on a bike than its ability to brake properly. Giant ATX 810 is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
ATX 810 comes in 7 sizes, that range from 152 cm – 193 cm (4.99 ft – 6.33 ft). In short, you can easily find one that suits you.
