Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
155cm - 165cm
SM
160cm - 171cm
MD
169cm - 181cm
LG
179cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminum
Suspension Fork
SR Suntour NEX 4110mm, 63mm travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Altus M310
Front Derailleur
Shimano Tourney
Shift Levers
Shimano ST-EF 500
Cassette
Shimano Altus CS-HG31, 11x32
Crank
ProWheel TY-CM99, 28/38/48
Bottom Bracket
sealed cartridge
Chain
KMC Z72
Pedals
platform plus comfort
Wheels
Rims
Giant GX28 disc wheelset
Tires
Giant P-X3 Multi-Surface, 700x45
Brakes
Brakes
TKB-172 mechanical disc brake F[160 rotor] R[160 rotor]
Brake Levers
Shimano ST-EF 500
Cockpit
Stem
alloy adjustable
Handlebar
alloy, high
Seat
Saddle
Giant Comfort
Seatpost
alloy suspension, 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.612 mm | 1.554 mm | 1.546 mm | 1.555 mm | 1.551 mm |
| Stack | 606 mm | 606 mm | 620 mm | 639 mm | 653 mm |
| Reach | 376 mm | 390 mm | 401 mm | 411 mm | 421 mm |
| Top Tube Length | 550 mm | 570 mm | 585 mm | 600 mm | 615 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 150 mm | 150 mm | 165 mm | 185 mm | 200 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1074 mm | 1089 mm | 1105 mm | 1121 mm | 1137 mm |
| Standover Height | 726 mm | 744 mm | 782 mm | 808 mm | 833 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 160 cm | 169 cm | 179 cm | 189 cm |
| Rider Max Height | 165 cm | 171 cm | 181 cm | 191 cm | 200 cm |
About this model
Cypress DX M Disc is part of the Giant Cypress model. There are 55 bikes that carry this model name. You can easily view all of the Giant Cypress bikes models from 2019, here.
Model range prices
The most economical model, the Giant Cypress 2019 has a starting price of 390$. Giant Cypress DX M Disc 2019 on the other hand is the most expensive at 525$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Comfort bikes average price
According to our math, the average price for a trustworthy Comfort bike is 360$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Comfort bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2019 and its price was 525$. Comparing this to the average Comfort bike price, we see that the price is 45.83% more expensive.
Overview of components
Fork
The SunTour NEX is included from the factory. It has a travel distance of 63mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When leaving the production line, the Cypress DX M Disc model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Cypress DX M Disc has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Cypress DX M Disc comes in 5 sizes, that range from 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, finding one for you shouldn’t be a problem.
