Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Alivio, Acera -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 171cm
MD
169cm - 181cm
LG
179cm - 191cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminum, disc
Suspension Fork
Advanced-Grade Composite, composite OverDrive steerer, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Alivio
Front Derailleur
Shimano Acera
Shift Levers
Shimano Altus, 2x9
Cassette
Shimano CS-HG200, 11x36
Crank
Shimano MT-210, 30/46 XS:170mm, S:170mm, M:170mm, L:175mm, XL:175mm
Bottom Bracket
Shimano SM-BB52
Chain
KMC X9 with Missing Link
Pedals
Giant Urban Fitness
Wheels
Front Hub
alloy, 28h
Rear Hub
alloy, 28h
Rims
Giant double wall aluminum
Spokes
stainless, 14g
Tires
Giant S-X2, puncture protect, 700x38c
Brakes
Brakes
Tektro HD-R280, Giant MPH rotors [F]160mm, [R]160mm
Brake Levers
Shimano
Cockpit
Stem
Giant Sport, 15-degree, 31.8mm XS:80mm, S:90mm, M:90mm, L:100mm, XL:100mm
Handlebar
Giant Sport XC, 31.8mm XS:60cm, S:64cm, M:64cm, L:68cm, XL:68cm
Grips
Giant ErgoContact
Seat
Saddle
Giant Sport
Seatpost
Giant D-Fuse, alloy XS:300mm, S:300mm, M:350mm, L:350mm, XL:350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.33 mm | 1.36 mm | 1.41 mm | 1.45 mm |
| Front Center | 636 mm | 637 mm | 653 mm | 669 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 76 mm | 69.4 mm | 69.4 mm | 69.4 mm |
| Stack | 534 mm | 552 mm | 581 mm | 609 mm |
| Reach | 402 mm | 406 mm | 412 mm | 419 mm |
| Top Tube Length | 561 mm | 576 mm | 591 mm | 606 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 430 mm | 485 mm | 535 mm | 585 mm |
| Head Tube Angle | 70 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 115 mm | 130 mm | 160 mm | 190 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1070 mm | 1071 mm | 1087 mm | 1103 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 710 mm | 750 mm | 795 mm | 838 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 169 cm | 179 cm | 189 cm |
| Rider Max Height | 171 cm | 181 cm | 191 cm | 200 cm |
Model Overview
Escape Disc 1 belongs to the Giant Escape model. 106 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Giant Escape 3 2023 is the most affordable bike of this model and has a price of 505$. On the other hand, Giant Escape Disc 1 2023, is the most expensive and costs 860$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Fitness bikes
Our math shows that the average cost of a dependable Fitness bike is 656$. However, even if your budget is less than the average, you might still be able to get a top-quality Fitness bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2023 and its price was 860$. Comparing this to the average Fitness bike price, we see that the price is 31.1% higher.
Escape Disc 1 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When leaving the production line, the Escape Disc 1 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Giant Escape Disc 1 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 160 cm – 200 cm (5.25 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
