Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset R350, Shimano -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum
Suspension Fork
Composite-grade composite, alloy OverDrive steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano R350
Front Derailleur
Shimano R460
Shift Levers
Shimano R460
Cassette
Shimano HG62 11x34, 10-speed
Crank
Shimano R460, 34/48
Bottom Bracket
Shimano external
Chain
KMC X10
Pedals
Alloy w/resin cage
Wheels
Front Hub
Formula Sealed, [F] 24h, [R] 28h
Rear Hub
Formula Sealed, [F] 24h, [R] 28h
Rims
Giant P-R2, double wall
Spokes
Sapim Race, 14g
Tires
Giant P-R3, front and rear specific, FlatGuard Deflect 3, 700x28
Brakes
Brakes
Tektro RX-1, mini linear pull
Brake Levers
Tektro Alloy
Cockpit
Stem
Giant Connect
Handlebar
Giant Sport, flat, 31.8mm
Seat
Saddle
Liv/giant Contact, Forward
Seatpost
Giant Connect Composite, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Top Tube Length | 546 mm | 559 mm | 572 mm | 584 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 135 mm | 145 mm | 155 mm | 229 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1067 mm | 1072 mm | 1080 mm | 1092 mm |
| Standover Height | 709 mm | 724 mm | 737 mm | 787 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
Escape RX W completes the Giant Escape model. 106 bikes variations carry this model name so far. Take a sneak peek at all Giant Escape bikes models from 2014, by clicking here.
Model range prices
Giant Escape 3 W 2014 is the cheapest bike model and costs 330$. Giant Escape RX Composite 2014 is the most expensive one and costs 1550$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Commuter bikes average price
If you want to purchase a solid Commuter bike, it is important to know that the average cost is 762$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Giant released this model in 2014, its price was 1125$. Comparing this to the average Commuter bike price, we see that the price is 47.64% higher.
Escape RX W components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When it comes to wheels, the Escape RX W bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Giant Escape RX W is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Giant Escape RX W bike has 4 sizes, in the range of 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, you won’t have a problem finding one that suits you.
