Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork SunTour RAIDON
-
Groupset Deore, FSA -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum, Semi-Internal Cable Routing
Suspension Fork
SR Suntour Raidon XC LOR DS, 15mm thru-axle, OverDrive, 120mm travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Deore Shadow +
Front Derailleur
Shimano Deore
Shift Levers
Shimano Deore
Cassette
FSA Comet, 26/36
Crank
FSA Comet, 26/36
Bottom Bracket
FSA, Press fit
Chain
KMC X10 w/ Missing Link
Pedals
Platform, caged
Wheels
Front Hub
Giant Tracker Sport, [F] 15mm thru-axle, [R] QR
Rear Hub
Giant Tracker Sport, [F] 15mm thru-axle, [R] QR
Rims
Giant XC-2 Disc, Tubeless
Spokes
Sapim Leader, 14g
Tires
Maxxis Ardent, 27.5x2.25, Tubeless, 60TPI
Brakes
Brakes
Shimano M315, hydraulic disc, [F] 180mm, [R] 160mm
Brake Levers
Shimano BL-M315
Cockpit
Stem
Giant Connect
Handlebar
Giant Connect Trail
Seat
Saddle
Giant Contact Neutral
Seatpost
Giant Contact Switch, dropper, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.39 mm | 1.37 mm | 1.35 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 688 mm | 710 mm | 732 mm | 753 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 105 mm | 105 mm | 105 mm | 105 mm |
| Stack | 595 mm | 605 mm | 618 mm | 632 mm |
| Reach | 418 mm | 435 mm | 451 mm | 467 mm |
| Top Tube Length | 592 mm | 612 mm | 632 mm | 652 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 390 mm | 445 mm | 480 mm | 530 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 110 mm | 125 mm | 140 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1116 mm | 1138 mm | 1160 mm | 1181 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 721 mm | 750 mm | 760 mm | 793 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Fathom 2 belongs to the Giant Fathom model. 29 bikes variations carry this model name so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Giant Fathom 29 2 2018 is the most economical model, with a starting price of 1070$. Giant Fathom 1 2018 on the other hand costs 1480$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1175$. Comparing the average cost of a Trail bike to this one, you will see that Fathom 2 price is 135.06% smaller.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
Giant Fathom 2 2018 bike is equipped with the SunTour RAIDON fork, and has 120mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
As for the wheels, Giant Fathom 2 2018, has a 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Giant Fathom 2 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Giant Fathom 2 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
Giant Fathom 2 includes a dropper post. Therefore, climbing or descending will be a breeze.
