Giant Fathom E+ 1 Pro 29 Electric Bike 2020
2020 E-bike
Estimate price |
4,013$
Weight | 23.4 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork RockShox Recon Silver RL
-
Groupset SX Eagle, SRAM -
Suspension Hardtail -
Motor Yamaha 80Nm mid-drive -
Battery Giant EnergyPak 500, 36V 13.8Ah integrated Lithium-Ion -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL aluminum, Overdrive 1½ - 1?" head tube, 148x12mm Thru-Axle, integrated KS18 kickstand mount
Suspension Fork
Rock Shox Recon RL 120mm travel, Tapered 1½ - 1?" steerer,110x15QR, lockout
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM SX Eagle
Front Derailleur
-
Shift Levers
SRAM SX Eagle
Cassette
SRAM Eagle PG-1210, 11-50T, 12-Speed
Crank
SRAM X-Sync 38T chainring Praxis e-Cadet+ custom forged crankarm set
Bottom Bracket
N/A
Chain
SRAM SX Eagle
Pedals
-
Wheels
Front Hub
Giant eTracker Boost, Sealed cartridge bearing, 6-bolt, [F] 110x15 [R] 148x12mm Thru-axle
Rear Hub
Giant eTracker Boost, Sealed cartridge bearing, 6-bolt, [F] 110x15 [R] 148x12mm Thru-axle
Rims
Giant XCT 29 Tubeless Ready 25mm e-bike optimized
Spokes
Sapim E-Lite [r] Race [f]
Tires
Maxxis Forekaster 29x2.35, foldable, 60 TPI, EXO, Tubeless Ready
Brakes
Brakes
Shimano MT400, Hydraulic Disc, 180/203mm
Brake Levers
Shimano MT401 Hydraulic Disc
Cockpit
Stem
Giant Contact
Handlebar
Giant Connect TR Riser 31.8x780mm
Seat
Saddle
Giant Sport
Seatpost
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
Motor & Battery
Motor
Giant SyncDrive Pro, automatic support, 5-mode, 50-360% tunable support, 80Nm, powered by YAMAHA
Battery
Giant EnergyPak 500, 36V 13.8Ah integrated Lithium-Ion
Remote
Giant RideControl ONE
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.48 mm | 1.44 mm |
| Bottom Bracket Height | 329 mm | 329 mm | 329 mm |
| Front Center | 700 | 726 mm | 751 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 95.7 mm | 95.7 mm | 95.7 mm |
| Stack | 623 mm | 632 mm | 646 mm |
| Reach | 405 mm | 427 mm | 448 mm |
| Top Tube Length | 597 mm | 622 mm | 647 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 465 mm | 505 mm | 535 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 115 mm | 125 mm | 140 mm |
| Chainstay Length | 472 mm | 472 mm | 472 mm |
| Wheelbase | 1168 mm | 1194 mm | 1220 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm |
| Standover Height | 757 mm | 784 mm | 788 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
Fathom E+ 1 Pro 29 Electric Bike completes the Giant E Fathom model. Giant released 25 e-bikes variations of this model so far. Take a sneak peek at all Giant E Fathom e-bikes models from 2020, by clicking here.
Model range prices
Giant Fathom E+ 3 Electric Bike 2020 is the cheapest e-bike model and costs 2432$. Giant Fathom E+ 1 Pro Electric Bike 2020 is the most expensive one and costs 3648$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail e-bikes
Our math shows that the average cost of a dependable Trail e-bike is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
At the moment of the release date, Giant Fathom E+ 1 Pro 29 Electric Bike price was 3648$. In conclusion, this e-bike price is 8.41% higher than the price of the average Trail e-bike.
Trail e-bikes average weight
On a deeper look, we notice that the average weight of a Trail e-bike is 23.7 kg (52.25 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Giant Fathom E+ 1 Pro 29 Electric Bike it’s weighing 23.4 kg (51.59 lbs). At this weight, is slightly lighter than average. In other words, this model is 1.28% lighter than the average Trail e-bike.
Fathom E+ 1 Pro 29 Electric Bike components
Fork
This e-bike has the RockShox Recon Silver RL fork installed. The fork’s travel is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When leaving the production line, the Fathom E+ 1 Pro 29 Electric Bike model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Fathom E+ 1 Pro 29 Electric Bike comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Giant Fathom E+ 1 Pro 29 Electric Bike e-bike has 3 sizes, in the range of 165 cm – 198 cm (5.41 ft – 6.5 ft). In short, it won’t be difficult to find the right one for you.
