Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-grade composite, Electronic ready
Suspension Fork
Advanced-grade composite, Hybrid OverDrive steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano Ultegra
Shift Levers
Shimano Ultegra
Cassette
Shimano Ultegra 11x28, 11-speed
Crank
Shimano Ultegra, 36/52
Bottom Bracket
Shimano, Press Fit
Chain
KMC X11L
Pedals
N/A
Wheels
Front Hub
Giant Performance Tracker Road, Sealed bearing, [F] 16h [R] 24h
Rear Hub
Giant Performance Tracker Road, Sealed bearing, [F] 16h [R] 24h
Rims
Giant PA-2, Aero
Spokes
Sapim Race, 14/15g
Tires
Giant P-SL 1, 700x23, Front and rear specific, Folding
Brakes
Brakes
SpeedControl SL
Brake Levers
Shimano Ultegra
Cockpit
Stem
Giant Connect
Handlebar
Giant Contact, 31.8mm
Seat
Saddle
Giant Performance Road
Seatpost
Giant Vector, Composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.416 mm | 1.433 mm | 1.448 mm | 1.445 mm | 1.444 mm |
| Stack | 517 mm | 534 mm | 553 mm | 566 mm | 581 mm | 595 mm |
| Reach | 372 mm | 377 mm | 386 mm | 391 mm | 402 mm | 412 mm |
| Top Tube Length | 515 mm | 535 mm | 555 mm | 570 mm | 585 mm | 605 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° | 72 ° |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 120 mm | 135 mm | 150 mm | 170 mm | 185 mm | 200 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 972 mm | 974 mm | 980 mm | 991 mm | 1006 mm | 1021 mm |
| Standover Height | 742 mm | 767 mm | 790 mm | 813 mm | 836 mm | 848 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
Model Overview
Propel Advanced 1 is a Giant Propel model. Giant released 102 bikes variations of this model so far. Take a sneak peek at all Giant Propel bikes models from 2016, by clicking here.
Model range prices
Giant Propel Advanced 2 2016 is the cheapest bike model and costs 2100$. Giant Propel Advanced SL 0 2016 is the most expensive one and costs 9000$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Aero bikes
If you want an acceptable Aero bike you should know that the average price is 4211$. However, you could also get a good Aero bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2600$. In conclusion, this bike price is 61.96% lower than the price of the average Aero bike.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
As for the wheels, Giant Propel Advanced 1 2016, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Giant Propel Advanced 1 is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Giant Propel Advanced 1 bike has 6 sizes, in the range of 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, it won’t take much to find one that’s right for you.
