Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-grade composite
Suspension Fork
Advanced-grade composite, Hybrid OverDrive 2 steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano Ultegra
Shift Levers
Shimano Ultegra Hydraulic
Cassette
Shimano Ultegra 11x28, 11-Speed
Crank
Shimano Ultegra, 52/36
Bottom Bracket
Shimano, Press Fit
Chain
KMC X11EL-1
Pedals
N/A
Wheels
Front Hub
Giant SLR 1 Aero DBL Disc WheelSystem; Pawl driver, 12mm axles, [F] 16h [R] 21h
Rear Hub
Giant SLR 1 Aero DBL Disc WheelSystem; Pawl driver, 12mm axles, [F] 16h [R] 21h
Rims
Giant SLR 1 Aero DBL Disc WheelSystem; [F] 42mm, [R] 65mm deep, 23mm wide, Tubeless, Full composite
Spokes
Giant SLR 1 Aero DBL Disc WheelSystem; Dynamic Balanced Lacing, bladed stainless
Tires
Giant Gavia Race 1 Tubeless, 700x25, Folding
Brakes
Brakes
Shimano Ultegra, hydraulic disc, 140mm
Brake Levers
Shimano Ultegra, hydraulic disc
Cockpit
Stem
Giant Contact SL Aero, alloy
Handlebar
Giant Contact SL Aero, alloy
Seat
Saddle
Giant Contact Forward
Seatpost
Giant Vector composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.4 mm | 1.43 mm | 1.42 mm | 1.45 mm | 1.45 mm |
| Bottom Bracket Height | 266 mm | 268 mm | 268 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 577 mm | 575 mm | 581 mm | 601 mm | 611 mm | 625 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 70 mm | 60 mm | 57 mm | 57 mm | 57 mm | 57 mm |
| Stack | 514 mm | 526 mm | 542 mm | 559 mm | 578 mm | 592 mm |
| Reach | 369 mm | 375 mm | 380 mm | 395 mm | 399 mm | 409 mm |
| Top Tube Length | 512 mm | 532 mm | 547 mm | 567 mm | 577 mm | 602 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° | 72 ° |
| Seat Tube Length | 465 mm | 500 mm | 520 mm | 545 mm | 575 mm | 595 mm |
| Head Tube Angle | 71 ° | 72.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 120 mm | 130 mm | 145 mm | 165 mm | 185 mm | 200 mm |
| Chainstay Length | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm |
| Wheelbase | 969 mm | 967 mm | 973 mm | 994 mm | 1004 mm | 1018 mm |
| Bottom Bracket Drop | 70 mm | 67 mm | 67 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 741 mm | 766 mm | 784 mm | 804 mm | 826 mm | 840 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
About this model
Propel Advanced Disc completes the Giant Propel model. There are 102 bikes that carry this model name. Take a sneak peek at all Giant Propel bikes models from 2018, by clicking here.
Model range prices
Giant Propel Advanced Disc 2018 is the cheapest bike model and costs 3775$. Giant Propel Advanced SL 0 Disc 2018 is the most expensive one and costs 11530$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Aero bikes average price
According to our math, the average price for a trustworthy Aero bike is 4211$. However, even if your budget is less than the average, you might still be able to get a top-quality Aero bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2018 for 3775$. Comparing the average cost of an Aero bike to this one, you will see that Propel Advanced Disc price is 11.55% lower.
Propel Advanced Disc components
Fork material
Propel Advanced Disc has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When it comes to wheels, the Propel Advanced Disc bike is equipped with the 700c carbon model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Giant Propel Advanced Disc has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 155 cm – 200 cm (5.09 ft – 6.56 ft). In short, it won’t be difficult to find the right one for you.
