Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 170mm -
Travel Rear 146mm -
Fork RockShox Yari RC
-
Groupset SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
163cm - 173cm
MD
170cm - 181cm
LG
178cm - 189cm
XL
186cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-Grade Aluminium front and rear triangles, 146mm Maestro suspension, 12x148mm thru-axle
Suspension Fork
RockShox Yari RC, 170mm, 15x110 Maxle Stealth, 44mm offset, custom tuned for Giant
Rear Shock
RockShox Deluxe Select+, custom tuned for Giant
Drivetrain
Rear Derailleur
Shimano SLX RD-M7100
Front Derailleur
N/A
Shift Levers
Shimano SLX SL-M7100, 1x12
Cassette
Shimano Deore M6100, 10x51
Crank
Shimano SLX, 32t S:165mm, M:170mm, L:170mm, XL:170mm
Bottom Bracket
Shimano, press fit
Chain
Shimano
Pedals
N/A
Wheels
Front Hub
Alloy, sealed bearing
Rear Hub
Alloy, sealed bearing
Rims
Giant AM 29, alloy
Spokes
Sapim
Tires
[F] Maxxis Assegai 29x2.5 WT, 3C MaxxTerra, EXO+, TR [R] Maxxis Minion DHR II 29x2.4 WT, 3C MaxxTerra, EXO+, TR tubeless
Brakes
Brakes
Shimano Deore BR-MT520, hydraulic, Shimano RT-66 rotors [F]203mm, [R]203mm
Brake Levers
Shimano Deore BL-MT501
Cockpit
Stem
Giant Contact SL 35 S:40mm, M:40mm, L:40mm, XL:40mm
Handlebar
Giant Contact TR35, alloy, 35mm
Grips
Giant Tactal Pro Single
Seat
Saddle
Giant Romero
Seatpost
Giant Contact Switch dropper, remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.38 mm | 1.29 mm | 1.25 mm |
| Bottom Bracket Height | 347 mm | 347 mm | 347 mm | 347 mm |
| Front Center | 753 mm | 782 mm | 824 mm | 851 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 132.7 mm | 132.7 mm | 132.7 mm | 132.7 mm |
| Stack | 619 mm | 619 mm | 628 mm | 637 mm |
| Reach | 420 mm | 448 mm | 485 mm | 508 mm |
| Top Tube Length | 571 mm | 598 mm | 637 mm | 663 mm |
| Seat Tube Angle | 76.4 ° | 76.4 ° | 76.4 ° | 76.4 ° |
| Seat Tube Length | 431 mm | 431 mm | 464 mm | 496 mm |
| Head Tube Angle | 64.6 ° | 64.6 ° | 64.6 ° | 64.6 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1188 mm | 1217 mm | 1259 mm | 1286 mm |
| Bottom Bracket Drop | 27 mm | 27 mm | 27 mm | 27 mm |
| Standover Height | 754 mm | 756 mm | 778 mm | 801 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 163 cm | 170 cm | 178 cm | 186 cm |
| Rider Max Height | 173 cm | 181 cm | 189 cm | 198 cm |
About this model
Reign 29 completes the Giant Reign model. Giant launched 92 bikes of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Giant Reign 29 2022 is the most affordable bike of this model and has a price of 2993$. On the other hand, Giant Reign Advanced Pro 29 1 2022, is the most expensive and costs 5922$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2022 for 2993$. Comparing this to the average Trail bike price, we see that the price is 8.36% higher.
Overview of components
Fork
The RockShox Yari RC is included from the factory. It has a travel distance of 170mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
From the factory, it comes with the RockShox Deluxe Select+ rear shock model, which has a travel of 146mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The Reign 29 2022 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 163 cm – 198 cm (5.35 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
