Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Factory Float 38
-
Groupset X01 Eagle, Praxis -
Suspension Full -
Motor Yamaha 250W 85Nm mid-drive -
Battery EnergyPak Smart 750Wh,EnergyPak Plus range extender compatible -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade Aluminum, Advanced Forged Composite Upper Rocker, 160mm Maestro suspension system, 'Boost' 148x12mm, UDHTM derrailleur hanger
Suspension Fork
Fox 38 Float Factory 29er, 170mm travel, GRIP2 VVC Damper, Boost 110x15 Kabolt floating axle, with fender, e-Bike optimised
Rear Shock
Fox Float X2 Factory, EVOL Large Volume sleeve, 2-position lever, 205x62.5mm Trunnion mount, custom tuned
Drivetrain
Rear Derailleur
SRAM XO1 Eagle
Front Derailleur
MRP 1X HD2 custom co-molded chain guide
Shift Levers
SRAM XO1 Eagle
Cassette
SRAM PG-1230, 11-50T, 12-speed
Crank
SRAM X-Sync Eagle 36T chainringPraxis e-Carbon custom carbon crankarm set (S/M:160, L/XL:165)
Bottom Bracket
N/A
Chain
SRAM XO1 Eagle PowerLock
Pedals
Flat pedal
Wheels
Front Hub
Giant e-TRX [F] 110x15 [R] 148x12mm Thru-axle
Rear Hub
Giant e-TRX [F] 110x15 [R] 148x12mm Thru-axle
Rims
Giant e-TRX 27.5"/29", Tubeless ready, 30mm inner width
Spokes
Giant e-TRX
Tires
Maxxis Minion DHF 29x2.6" foldable, Tubeless, EXO+, 3C MaxxTerra[F]Maxxis High Roller II 27.5x2.5" foldable, Tubeless, DoubleDown, 3C MaxxTerra Compound [R]
Brakes
Brakes
SRAM Code RSC, hydraulic disc, 220mm[F] /200mm[R]
Brake Levers
SRAM Code RSC
Cockpit
Stem
Giant Contact SL 35
Handlebar
Giant Contact Trail SL, 35x800mm
Grips
Giant Tactal Pro-E, single lock-on
Seat
Saddle
Giant Romero
Seatpost
Giant Contact Switch, dropper, 30,9mm (S:125, M: 150, L/XL:170)
Motor & Battery
Motor
SyncDrive Pro, 85Nm, powered by Yamaha
Battery
EnergyPak Smart 750Wh,EnergyPak Plus range extender compatible
Charger
EnergyPak 6A smart charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.496 mm | 1.389 mm | 1.411 mm | 1.335 mm | 1.358 mm | 1.287 mm | 1.308 mm |
| Bottom Bracket Height | 359 mm | 349 mm | 359 mm | 349 mm | 359 mm | 349 mm | 359 mm | 349 mm |
| Front Center | 756 mm | 756 mm | 783 mm | 783 mm | 812 mm | 812 mm | 842 mm | 842 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 132.1 mm | 135.5 mm | 132 mm | 135 mm | 132 mm | 135 mm | 132.1 mm | 135.5 mm |
| Stack | 632 mm | 636 mm | 632 mm | 635 mm | 641 mm | 645 mm | 650 | 654 mm |
| Reach | 430 mm | 425 mm | 455 mm | 450 mm | 480 mm | 475 mm | 505 mm | 500 mm |
| Top Tube Length | 568 mm | 569 mm | 594 mm | 595 mm | 621 mm | 622 mm | 648 mm | 649 mm |
| Seat Tube Angle | 77.5 ° | 76.7 ° | 77.5 ° | 76.7 ° | 77.5 ° | 76.7 ° | 77.5 ° | 76.7 ° |
| Seat Tube Length | 400 mm | 400 mm | 425 mm | 425 mm | 450 mm | 450 mm | 475 mm | 475 mm |
| Head Tube Angle | 64.5 ° | 63.7 ° | 64.5 ° | 63.7 ° | 64.5 ° | 63.7 ° | 64.5 ° | 63.7 ° |
| Head Tube Length | 100 mm | 100 mm | 100 mm | 100 mm | 110 mm | 110 mm | 120 mm | 120 mm |
| Chainstay Length | 454 mm | 454 mm | 454 mm | 454 mm | 454 mm | 454 mm | 454 mm | 454 mm |
| Wheelbase | 1210 mm | 1209 mm | 1237 mm | 1236 mm | 1266 mm | 1265 mm | 1296 mm | 1295 mm |
| Bottom Bracket Drop | 15 mm | 25 mm | 15 mm | 25 mm | 15 mm | 25 mm | 15 mm | 25 mm |
| Standover Height | 789 mm | 785 mm | 776 mm | 772 mm | 775 mm | 771 mm | 772 mm | 768 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
About this model
Reign E+ 0 is part of the Giant E Reign model. Giant released 16 e-bikes variations of this model so far. Take a sneak peek at all Giant E Reign e-bikes models from 2021, by clicking here.
Model range prices
The most economical model, the Giant Reign E+ 2 2021 has a starting price of 7297$. Giant Reign E+ 0 2021 on the other hand is the most expensive at 9730$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro e-bikes
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 9730$. If we compare this with the average Enduro e-bike cost we notice that the price is 103.34% more expensive.
Overview of components
Fork
The fork installed on this bike is the Fox Factory Float 38 model. The travel on this model is 170mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The shock that’s installed on this e-bike is Fox Float X2 Factory, with a travel distance of 160mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When leaving the production line, the Reign E+ 0 model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Giant Reign E+ 0 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Dropper post
Every bike should have a dropper post, and this one does. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
