Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Performance Elite Float 38
-
Groupset XT, Praxis -
Suspension Full -
Motor Yamaha 85Nm mid-drive -
Battery EnergyPak Smart 625WhEnergyPak Plus range extender compatible -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade Aluminum, Advanced Forged Composite Upper Rocker, 160mm Maestro suspension system, 'Boost' 148x12mm, UDHTM derrailleur hanger
Suspension Fork
Fox 38 Float Performance Elite 29er, 170mm travel, GRIP2 VVC Damper, Boost 110x15 Kabolt floating axle, e-Bike optimized
Rear Shock
Fox Float X2 Performance Elite, EVOL Large Volume sleeve, 2-position lever, 205x62.5mm Trunnion mount, custom tuned
Drivetrain
Rear Derailleur
Shimano Deore XT, 12-Speed, Shadow+
Front Derailleur
MRP 1X HD2 custom co-molded chain guide
Shift Levers
Shimano Deore XT
Cassette
Shimano HG-M7100, 10-51T, 12-speed
Crank
Praxis Wavetm 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (S/M:160, L/XL:165)
Bottom Bracket
N/A
Chain
KMC e.12 Turbo, EcoProteq, e-bike optimized
Pedals
Flat pedal
Wheels
Front Hub
Giant e-TR1 [F] 110x15 [R] 148x12mm Thru-axle
Rear Hub
Giant e-TR1 [F] 110x15 [R] 148x12mm Thru-axle
Rims
Giant e-TR1 29"[F] 27.5"[R], Tubeless ready, 30mm inner width
Spokes
Giant e-TR1
Tires
Maxxis Minion DHF 29x2.6" foldable, Tubeless, EXO+, 3C MaxxTerra[F]Maxxis High Roller II 27.5x2.5" foldable, Tubeless, DoubleDown, 3C MaxxTerra Compound [R]
Brakes
Brakes
Shimano Deore XT, BR-M8120, 4-piston, hydraulic disc, 203mm
Brake Levers
Shimano Deore XT BL-M8100, I-spec EV
Cockpit
Stem
Giant Contact SL 35
Handlebar
Giant Contact Trail, 35x800mm
Grips
Giant Tactal Pro-E, single lock-on
Seat
Saddle
Giant Romero Trail
Seatpost
Giant Contact Switch, dropper, 30,9mm (S:125, M: 150, L/XL:170)
Motor & Battery
Motor
SyncDrive Pro, 85Nm, powered by Yamaha
Battery
EnergyPak Smart 625WhEnergyPak Plus range extender compatible
Remote
RideControl GO, frame integrated LED displayANT+ Wireless display compatible
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.496 mm | 1.411 mm | 1.358 mm | 1.308 mm |
| Bottom Bracket Height | 251 mm | 251 mm | 251 mm | 251 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 135.55 mm | mm | mm | 135.55 mm |
| Seat Tube Angle | 76.7 ° | 76.7 ° | 76.7 ° | 76.7 ° |
| Seat Tube Length | 400 mm | 425 mm | 450 mm | 475 mm |
| Head Tube Angle | 63.7 ° | 63.7 ° | 63.7 ° | 63.7 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm |
| Bottom Bracket Drop | 104 mm | 104 mm | 104 mm | 104 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Reign E+ 1 is a Giant E Reign model. 16 e-bikes variations carry this model name so far. You can easily view all of the Giant E Reign e-bikes models from 2022, here.
Model range prices
Giant Reign E+ 2 2022 is the most affordable e-bike of this model and has a price of 4989$. On the other hand, Giant Reign E+ 0 2022, is the most expensive and costs 6724$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro e-bikes
If you want an acceptable Enduro e-bike you should know that the average price is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
When Giant released this model in 2022, its price was 5929$. In conclusion, this e-bike price is 23.91% more expensive than the price of the average Enduro e-bike.
Overview of components
Fork
The Reign E+ 1 comes factory-installed with the Fox Performance Elite Float 38 fork. This has a travel range of 170mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The shock that’s installed on this e-bike is Fox Float X2 Performance Elite, with a travel distance of 160mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The wheels on Reign E+ 1 are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Reign E+ 1 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the Reign E+ 1. Therefore, climbing or descending will be a breeze.
