Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 170mm -
Travel Rear 160mm -
Fork RockShox Domain
-
Groupset Deore, Praxis -
Suspension Full -
Motor Yamaha 250W 85Nm mid-drive -
Battery EnergyPak Smart 800,EnergyPak Plus range extender compatible (exclude S Size) -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM High
163cm - 174cm
SM Low
163cm - 174cm
MD High
171cm - 182cm
MD Low
171cm - 182cm
LG High
179cm - 190cm
LG Low
179cm - 190cm
XL High
187cm - 198cm
XL Low
187cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum, Advanced Forged Composite Upper Rocker, 160mm Maestro suspension system, 'Boost' 148x12mm, Universal Derailleur Hanger
Suspension Fork
RockShox Domain R 29er, 170mm travel, 15x110 Boost, Maxle Stealth, E-bike Approved
Rear Shock
Fox Float DPS Performance, EVOL Large Volume sleeve, 2-position lever, 205x62.5mm Trunnion mount, custom tuned
Drivetrain
Rear Derailleur
Shimano Deore 12-speed
Front Derailleur
MRP 1X HD2 custom co-molded chain guide
Shift Levers
Shimano Deore
Cassette
Shimano Deore CS-M6100-12, 10-51T, 12-speed
Crank
Praxis Wavetm 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (S/M:160, L/XL:165)
Bottom Bracket
n/a
Chain
KMC e.12 Turbo, EcoProteq, e-bike optimized
Pedals
Flat pedal
Wheels
Front Hub
Shimano MT410 Boost, Center-Lock, [F] 110x15 [R] 148x12mm Micro-Spline Drive Body Thru-axle
Rear Hub
Shimano MT410 Boost, Center-Lock, [F] 110x15 [R] 148x12mm Micro-Spline Drive Body Thru-axle
Rims
Giant AM 29" [F] 27.5"[R], Tubeless ready, 30mm inner width
Spokes
Sapim E-Lite [R] Race [F], e-bike optimized
Tires
Maxxis Minion DHF 29x2.6" foldable, Tubeless, EXO+, 3C MaxxTerra[F]Maxxis High Roller II 27.5x2.5" foldable, Tubeless, DoubleDown, 3C MaxxTerra Compound [R]
Brakes
Brakes
Shimano Deore BR-M420, 4-piston, hydraulic disc, 203mm
Brake Levers
Shimano Deore, I-spec EV
Cockpit
Stem
Giant Contact SL 35
Handlebar
Giant Contact Trail, 35x800mm
Grips
Giant Tactal Pro-E, single lock-on
Seat
Saddle
Giant Romero Trail
Seatpost
Giant Contact Switch, dropper, 30,9mm (S:125/M:150/ L&XL:170)
Motor & Battery
Motor
SyncDrive Pro, 85Nm, powered by Yamaha
Battery
EnergyPak Smart 800,EnergyPak Plus range extender compatible (exclude S Size)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.496 mm | 1.389 mm | 1.411 mm | 1.335 mm | 1.358 mm | 1.287 mm | 1.308 mm |
| Bottom Bracket Height | 340 mm | 330 mm | 340 mm | 330 mm | 340 mm | 330 mm | 340 mm | 330 mm |
| Front Center | 755 mm | 753 mm | 783 mm | 783 mm | 812 mm | 812 mm | 842 mm | 842 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 132.1 mm | 135.5 mm | 132 mm | 135 mm | 132 mm | 135 mm | 132.1 mm | 135.5 mm |
| Stack | 632 mm | 636 mm | 632 mm | 635 mm | 641 mm | 645 mm | 650 | 654 mm |
| Reach | 430 mm | 425 mm | 455 mm | 450 mm | 480 mm | 475 mm | 505 mm | 500 mm |
| Top Tube Length | 568 mm | 569 mm | 594 mm | 595 mm | 621 mm | 622 mm | 648 mm | 649 mm |
| Seat Tube Angle | 77.5 ° | 76.7 ° | 77.5 ° | 76.7 ° | 77.5 ° | 76.7 ° | 77.5 ° | 76.7 ° |
| Seat Tube Length | 400 mm | 400 mm | 425 mm | 425 mm | 450 mm | 450 mm | 475 mm | 475 mm |
| Head Tube Angle | 64.5 ° | 63.7 ° | 64.5 ° | 63.7 ° | 64.5 ° | 63.7 ° | 64.5 ° | 63.7 ° |
| Head Tube Length | 100 mm | 100 mm | 100 mm | 100 mm | 110 mm | 110 mm | 120 mm | 120 mm |
| Chainstay Length | 455 mm | 457 mm | 454 mm | 454 mm | 454 mm | 454 mm | 454 mm | 454 mm |
| Wheelbase | 1210 mm | 1209 mm | 1237 mm | 1236 mm | 1266 mm | 1265 mm | 1296 mm | 1295 mm |
| Bottom Bracket Drop | 15 mm | 25 mm | 15 mm | 25 mm | 15 mm | 25 mm | 15 mm | 25 mm |
| Standover Height | 789 mm | 785 mm | 776 mm | 772 mm | 775 mm | 771 mm | 772 mm | 768 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 163 cm | 163 cm | 171 cm | 171 cm | 179 cm | 179 cm | 187 cm | 187 cm |
| Rider Max Height | 174 cm | 174 cm | 182 cm | 182 cm | 190 cm | 190 cm | 198 cm | 198 cm |
About this model
Reign E+ 3, belongs to the Giant E Reign model. There are 16 e-bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Giant Reign E+ 3, 2023 is the most affordable e-bike of this model and has a price of 5900$. On the other hand, Giant Reign E+ 1 2023, is the most expensive and costs 7014$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Enduro e-bikes average price
According to our calculations, the average cost of an Enduro e-bike that is reliable is 4785$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Giant Reign E+ 3, price was 5900$. Comparing this to the average Enduro e-bike price, we see that the price is 23.3% more expensive.
Reign E+ 3, components
Fork
Giant Reign E+ 3, 2023 e-bike is equipped with the RockShox Domain fork, and has 170mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this e-bike has the Fox Float DPS Performance model, with a travel of 160mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When it comes to wheels, the Reign E+ 3, e-bike is equipped with the 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Giant Reign E+ 3, has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 8 sizes. They vary from 163 cm – 198 cm (5.35 ft – 6.5 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Every bike should have a dropper post, and this one does. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
