Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Rear 170mm -
Suspension Full
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-Grade Aluminum w/ ISCG Tabs, 6.7" Maestro Suspension
Rear Shock
Fox DHX 5.0 Air, Factory
Drivetrain
Bottom Bracket
73mm English threaded BB shell w/ ISCG chain guide tabs, bearing set not included
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Top Tube Length | 569 mm | 589 mm | 612 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72 ° |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 117 mm | 127 mm | 150 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1120 mm | 1140 mm | 1161 mm |
| Standover Height | 721 mm | 749 mm | 777 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Reign X Frameset is part of the Giant Reign model. There are 92 frames that carry this model name. Check out the entire range from 2013 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Downhill frames average price
If you want an acceptable Downhill frame you should know that the average price is 1923$. However, even if your budget is less than the average, you might still be able to get a top-quality Downhill frame. As a general rule of thumb, you should always read reviews about the frame and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2013 for 1750$. Comparing this to the average Downhill frame price, we see that the price is 9.89% lower.
Overview of components
Rear Shock
From the factory, it comes with the Fox DHX 5.0 Air rear shock model, which has a travel of 170mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, always consider getting a bike that has a rear shock as well.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
