Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 170mm -
Fork RockShox
-
Groupset X9, X7 -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum, 6.7" Maestro suspension
Suspension Fork
RockShox Lyric RC, w/20mm thru-axle, OverDrive 2 steerer, 160mm travel
Rear Shock
RockShox Monarch Plus
Drivetrain
Rear Derailleur
SRAM X9, Type 2
Front Derailleur
SRAM X7
Shift Levers
SRAM X7, Trigger Shift
Cassette
SRAM PG1070 11x36, 10-speed
Crank
SRAM S1000, 24/36 w/MRP 2x Guide
Bottom Bracket
SRAM GXP
Chain
KMC X10
Pedals
N/A
Wheels
Front Hub
[F] Giant Tracker, w/20mm axle, 32h [R] DT Swiss 350, w/12mm Maxle axle, 32h
Rear Hub
[F] Giant Tracker, w/20mm axle, 32h [R] DT Swiss 350, w/12mm Maxle axle, 32h
Rims
Giant P-AM2, Double Wall
Spokes
DT Competition, 14/15g
Tires
Schwalbe Hans Dampf Performance, 26x2.35, folding
Brakes
Brakes
Avid Elixir 7 Trail, hydraulic disc, [F] 200mm, [R] 180mm
Brake Levers
Avid Elixir 7 Trail
Cockpit
Stem
Giant Connect SL, OverDrive 2
Handlebar
Giant Contact All Mountain, 31.8mm
Seat
Saddle
Giant Contact, Upright
Seatpost
Giant Contact Switch-R, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Top Tube Length | 569 mm | 589 mm | 612 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72 ° |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 117 mm | 127 mm | 150 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1120 mm | 1140 mm | 1161 mm |
| Standover Height | 721 mm | 749 mm | 777 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Reign X1 belongs to the Giant Reign model. There are 92 bikes that carry this model name. You can get a glimpse at all models from 2014, by clicking on this link.
Model range prices
The most economical model, the Giant Reign X1 2014 has a starting price of 3825$. Giant Reign X0 2014 on the other hand is the most expensive at 5850$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Downhill bikes
If you want to purchase a solid Downhill bike, it is important to know that the average cost is 3391$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Downhill bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Giant released this model in 2014, its price was 3825$. Comparing this to the average Downhill bike price, we see that the price is 12.8% more expensive.
Reign X1 components
Fork
The RockShox is included from the factory. It has a travel distance of 160mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
As for the rear shock, this bike has the RockShox Monarch Plus model, with a travel of 170mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The Reign X1 2014 bike is equipped with 27.5″ aluminum wheels when leaving the factory. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Reign X1 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Giant Reign X1 bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
