Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork RockShox
-
Groupset X5, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XXS
157cm - 167cm
XS
165cm - 173cm
SM
171cm - 179cm
MD
177cm - 185cm
LG
183cm - 191cm
XL
188cm - 197cm
XXL
194cm - 204cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Butted Aluminum
Suspension Fork
RockShox Dart 2, 100mm Travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM X.5
Front Derailleur
Shimano Altus
Shift Levers
SRAM X.5, Trigger
Cassette
SRAM PG830 11x32, 8-Speed
Crank
Shimano Acera M361, 22/32/42
Bottom Bracket
Shimano Cartridge
Chain
KMC Z72
Pedals
Alloy Platform
Wheels
Front Hub
Formula Disc, 32h
Rear Hub
Formula Disc, 32h
Rims
Giant XC Alloy, Double Wall
Spokes
Stainless Steel, 14g
Tires
Kenda Small Block Eight, 26x2.1
Brakes
Brakes
Avid BB5 Disc
Brake Levers
Tektro Alloy, 2 Finger
Cockpit
Stem
Giant Sport, Alloy
Handlebar
Giant Sport Alloy, Low Rise 31.8
Seat
Saddle
Giant Sport MTB
Seatpost
Giant Sport, Alloy, 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Top Tube Length | 521 mm | 541 mm | 569 mm | 579 mm | 592 mm | 617 mm | 635 mm |
| Seat Tube Angle | 75 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Angle | 70 ° | 69 ° | 69 ° | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 117 mm | 119 mm | 130 mm | 145 mm | 160 mm | 180 mm | 201 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1008 mm | 1031 mm | 1057 mm | 1077 mm | 1090 mm | 1105 mm | 1120 mm |
| Standover Height | 714 mm | 724 mm | 732 mm | 767 mm | 798 mm | 810 mm | 823 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 157 cm | 165 cm | 171 cm | 177 cm | 183 cm | 188 cm | 194 cm |
| Rider Max Height | 167 cm | 173 cm | 179 cm | 185 cm | 191 cm | 197 cm | 204 cm |
Model Overview
Revel 0 is part of the Giant Revel model. There are 43 bikes that carry this model name. Take a sneak peek at all Giant Revel bikes models from 2011, by clicking here.
Model range prices
Giant Revel 2 W 2011 is the most affordable bike of this model and has a price of 390$. On the other hand, Giant Revel 0 2011, is the most expensive and costs 670$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2011 for 670$. If we compare this with the average Crosscountry bike cost we notice that the price is 184.33% lower.
Revel 0 components
Fork
The Revel 0 comes factory-installed with the RockShox fork. This has a travel range of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The Revel 0 2011 bike is equipped with 26″ aluminum wheels when leaving the factory. Being a little smaller, these wheels will fit both small and tall riders. However, they provide less traction than 29″ wheels do.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Revel 0 comes with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Giant Revel 0 bike has 7 sizes, in the range of 157 cm – 204 cm (5.15 ft – 6.69 ft). In short, you can easily find one that suits you.
