Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork SunTour XCT
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-grade aluminum
Suspension Fork
SR Suntour XCT, 100mm travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tourney
Front Derailleur
Shimano Tourney
Shift Levers
Shimano EF40, Rapid Fire
Cassette
Shimano TZ31 14x34, 7-speed
Crank
SR Suntour NEX, 28/38/48
Bottom Bracket
SR Suntour sealed
Chain
KMC Z51
Pedals
Nylon platform
Wheels
Front Hub
Alloy Disc, 32h
Rear Hub
Alloy Disc, 32h
Rims
Giant Alloy, double wall
Spokes
Stainless Steel, 14g
Tires
Giant Sport, 26x2.1
Brakes
Brakes
Tektro Novela, mechanical disc, 160mm
Brake Levers
Shimano EF40
Cockpit
Stem
Giant Sport
Handlebar
High-tensile steel, low-rise, 25.4mm
Seat
Saddle
Giant Connect, Upright
Seatpost
Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Top Tube Length | 521 mm | 541 mm | 569 mm | 579 mm | 592 mm | 617 mm |
| Seat Tube Angle | 75 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72 ° | 72 ° |
| Head Tube Angle | 70 ° | 69 ° | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 117 mm | 119 mm | 130 mm | 145 mm | 160 mm | 180 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1008 mm | 1031 mm | 1057 mm | 1077 mm | 1090 mm | 1105 mm |
| Standover Height | 714 mm | 724 mm | 732 mm | 767 mm | 798 mm | 810 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" |
About this model
Revel 2 is part of the Giant Revel model. There are 43 bikes that carry this model name. You can easily view all of the Giant Revel bikes models from 2014, here.
Model range prices
Giant Revel Jr. Girls 20 2014 is the most economical model, with a starting price of 220$. Giant Revel 29er (2015) 2014 on the other hand costs 560$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 400$. If we compare this with the average Crosscountry bike cost we notice that the price is 376.25% smaller.
Overview of components
Fork
The Revel 2 comes factory-installed with the SunTour XCT fork. This has a travel range of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The wheels on Revel 2 are the 26″ aluminum type. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Giant Revel 2 is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
