Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 63mm -
Fork SunTour
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-grade aluminum
Suspension Fork
SR Suntour M3010AL, 63mm travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tourney
Front Derailleur
Shimano Tourney
Shift Levers
Shimano EF40, Rapid Fire
Cassette
Shimano TZ31 14x34, 7-speed
Crank
SR Suntour NEX, 28/38/48
Bottom Bracket
SR Suntour sealed
Chain
KMC Z51
Pedals
Nylon platform
Wheels
Front Hub
Alloy, 32h
Rear Hub
Alloy, 32h
Rims
Giant Alloy
Spokes
Stainless Steel, 14g
Tires
Kenda, 26x2.1
Brakes
Brakes
Alloy, linear pull
Brake Levers
Shimano EF40
Cockpit
Stem
Giant Sport
Handlebar
High-tensile steel, low-rise, 25.4mm
Seat
Saddle
Giant Connect, Upright
Seatpost
Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Top Tube Length | 521 mm | 541 mm | 569 mm | 579 mm | 592 mm | 617 mm |
| Seat Tube Angle | 75 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72 ° | 72 ° |
| Head Tube Angle | 70 ° | 69 ° | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 117 mm | 119 mm | 130 mm | 145 mm | 160 mm | 180 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1008 mm | 1031 mm | 1057 mm | 1077 mm | 1090 mm | 1105 mm |
| Standover Height | 714 mm | 724 mm | 732 mm | 767 mm | 798 mm | 810 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" |
About this model
Revel 3 is part of the Giant Revel model. There are 43 bikes that carry this model name. Take a sneak peek at all Giant Revel bikes models from 2014, by clicking here.
Model range prices
Giant Revel Jr. Girls 20 2014 is the cheapest bike model and costs 220$. Giant Revel 29er (2015) 2014 is the most expensive one and costs 560$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2014 and its price was 330$. Comparing the average cost of a Crosscountry bike to this one, you will see that Revel 3 price is 477.27% lower.
Overview of components
Fork
The fork installed on this bike is the SunTour model. The travel on this model is 63mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The wheels on Revel 3 are the 26″ aluminum type. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Giant Revel 3 has Rim brakes installed. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
