Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra, Shimano -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
162cm - 173cm
MD
169cm - 180cm
MD/LG
175cm - 186cm
LG
180cm - 192cm
XL
188cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum
Suspension Fork
Advanced-grade composite, Alloy OverDrive steerer, 15mm thru-axle
Drivetrain
Rear Derailleur
Shimano Tiagra
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiagra
Cassette
Shimano HG500 11x34, 10-speed
Crank
Shimano R460, 34/48
Bottom Bracket
Threaded, Sealed
Chain
KMC X10
Pedals
N/A
Wheels
Front Hub
Giant Performance Tracker Disc, Thru-axle, 32h
Rear Hub
Giant Performance Tracker Disc, Thru-axle, 32h
Rims
Giant PX-2 Disc
Spokes
Sapim Race, 14/15g
Tires
Giant SLX 2, 700x35, Deflect 2, Reflective sidewall, Folding
Brakes
Brakes
TRP Spyre-C, Mechanical disc, 160mm
Brake Levers
Shimano Tiagra w/ Tektro RL721 sub lever
Cockpit
Stem
Giant Connect
Handlebar
Giant Connect XR Ergo-control, 31.8mm
Seat
Saddle
Giant Connect, forward
Seatpost
Giant Connect, Composite, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|
| Top Tube Length | 554 mm | 564 mm | 569 mm | 579 mm | 584 mm |
| Seat Tube Angle | 72 ° | 72 ° | 71.5 ° | 71 ° | 71 ° |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 130 mm | 150 mm | 165 mm | 178 mm | 196 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1041 mm | 1046 mm | 1046 mm | 1052 mm | 1057 mm |
| Standover Height | 729 mm | 749 mm | 765 mm | 780 mm | 798 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 169 cm | 175 cm | 180 cm | 188 cm |
| Rider Max Height | 173 cm | 180 cm | 186 cm | 192 cm | 199 cm |
About this model
Revolt 1 belongs to the Giant Revolt model. 68 bikes variations carry this model name so far. Check out the entire range from 2016 of this model, by clicking this link.
Model range prices
Giant Revolt 3 2016 is the most affordable bike of this model and has a price of 1050$. On the other hand, Giant Revolt 1 2016, is the most expensive and costs 1300$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2016 and its price was 1300$. Comparing this to the average Gravel bike price, we see that the price is 89.38% smaller.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When leaving the production line, the Revolt 1 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
This bike is available in 5 sizes. They vary from 162 cm – 199 cm (5.31 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
