Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora, FSA -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS Short
155cm - 166cm
XS Long
155cm - 166cm
SM Short
159cm - 171cm
SM Long
159cm - 171cm
MD Short
169cm - 181cm
MD Long
169cm - 181cm
MD/LG
174cm - 186cm
MD/LG
174cm - 186cm
LG Short
179cm - 191cm
LG Long
179cm - 191cm
XL Short
189cm - 200cm
XL Long
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-grade aluminum, 12x142mm thru-axle, disc, flip chip dropout
Suspension Fork
Advanced-grade composite, full-composite OverDrive steerer, 12mm thru-axle, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Sora, long cage
Front Derailleur
Shimano Sora
Shift Levers
Shimano Sora, 2x9
Cassette
Shimano HG400, 11x34
Crank
FSA Vero Pro, 32/48 XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
Bottom Bracket
cartridge
Chain
KMC X9 with Missing Link
Pedals
N/A
Wheels
Front Hub
Giant alloy, 12mm thru-axle
Rear Hub
Giant alloy, 12mm thru-axle
Rims
Giant S-X2 Disc wheelset, alloy
Spokes
stainless
Tires
Giant CrossCut AT 2, 700x38c, tubeless
Brakes
Brakes
Tektro MD-C550 mechanical, Giant MPH rotors [F]160mm, [R]160mm
Brake Levers
Shimano Sora
Cockpit
Stem
Giant Sport, 8-degree XS:50mm, S:60mm, M:70mm, M/L:80mm, L:80mm, XL:90mm
Handlebar
Giant Contact XR Ergo-Control, 31.8mm XS:42cm, S:42cm, M:44cm, M/L:44cm, L:46cm, XL:46cm
Grips
cork tape with gel
Seat
Saddle
Giant Approach
Seatpost
Giant D-Fuse, alloy, 14mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS Short | XS Long | SM Short | SM Long | MD Short | MD Long | MD/LG | MD/LG | LG Short | LG Long | XL Short | XL Long |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.46 mm | 1.5 mm | 1.5 mm | 1.52 mm | 1.52 mm | 1.55 mm | 1.55 mm | 1.56 mm | 1.56 mm | 1.55 mm | 1.55 mm |
| Bottom Bracket Height | 269 mm | 268 mm | 269 mm | 268 mm | 269 mm | 268 mm | 269 mm | 268 mm | 269 mm | 268 mm | 269 mm | 268 mm |
| Front Center | 612 mm | 612 mm | 608 mm | 608 mm | 613 mm | 613 mm | 618 mm | 618 mm | 628 mm | 628 mm | 643 mm | 644 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 78 mm | 82 mm | 72 mm | 75 mm | 68 mm | 72 mm | 65 mm | 68 mm | 65 mm | 68 mm | 65 mm | 68 mm |
| Stack | 552 mm | 552 mm | 566 mm | 566 mm | 582 mm | 582 mm | 598 mm | 598 mm | 612 mm | 612 mm | 626 mm | 626 mm |
| Reach | 377 mm | 377 mm | 377 mm | 377 mm | 383 mm | 383 mm | 387 mm | 387 mm | 393 mm | 393 mm | 403 mm | 403 mm |
| Top Tube Length | 536 mm | 536 mm | 546 mm | 546 mm | 556 mm | 556 mm | 571 mm | 571 mm | 581 mm | 581 mm | 596 mm | 596 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 430 mm | 430 mm | 450 mm | 450 mm | 470 mm | 470 mm | 490 mm | 490 mm | 510 mm | 510 mm | 530 mm | 530 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° | 71 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 125 mm | 125 mm | 135 mm | 135 mm | 150 mm | 150 mm | 165 mm | 165 mm | 180 mm | 180 mm | 195 mm | 195 mm |
| Chainstay Length | 426 mm | 436 mm | 426 mm | 436 mm | 426 mm | 436 mm | 426 mm | 436 mm | 426 mm | 436 mm | 426 mm | 436 mm |
| Wheelbase | 1025 mm | 1035 mm | 1021 mm | 1031 mm | 1026 mm | 1036 mm | 1031 mm | 1041 mm | 1041 mm | 1051 mm | 1057 mm | 1067 mm |
| Bottom Bracket Drop | 80 mm | 81 mm | 80 mm | 81 mm | 80 mm | 81 mm | 80 mm | 81 mm | 80 mm | 81 mm | 80 mm | 81 mm |
| Standover Height | 713 mm | 720 mm | 730 mm | 737 mm | 748 mm | 755 mm | 765 mm | 772 mm | 782 mm | 789 mm | 797 mm | 806 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 155 cm | 159 cm | 159 cm | 169 cm | 169 cm | 174 cm | 174 cm | 179 cm | 179 cm | 189 cm | 189 cm |
| Rider Max Height | 166 cm | 166 cm | 171 cm | 171 cm | 181 cm | 181 cm | 186 cm | 186 cm | 191 cm | 191 cm | 200 cm | 200 cm |
About this model
Revolt 2 completes the Giant Revolt model. Giant released 68 bikes variations of this model so far. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
Giant Revolt 2 2024 is the most affordable bike of this model and has a price of 1229$. On the other hand, Giant Revolt X, Advanced Pro 0 2024, is the most expensive and costs 7000$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Gravel bikes average price
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1229$. Comparing the average cost of a Gravel bike to this one, you will see that Revolt 2 price is 100.33% lower.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The Revolt 2 2024 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Revolt 2 comes with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
This bike is available in 12 sizes. They vary from 155 cm – 200 cm (5.09 ft – 6.56 ft). In short, you can easily find one that suits you.
