Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Rival -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS Short
155cm - 166cm
XS Long
155cm - 166cm
SM Short
159cm - 171cm
SM Long
159cm - 171cm
MD Short
169cm - 181cm
MD Long
169cm - 181cm
MD/LG
174cm - 186cm
MD/LG
174cm - 186cm
LG Short
179cm - 191cm
LG Long
179cm - 191cm
XL Short
189cm - 200cm
XL Long
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-Grade Composite, 12x142mm thru-axle, disc, flip chip dropout
Suspension Fork
Advanced-Grade Composite, full-composite OverDrive steerer, 12mm thru-axle, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM Rival 1
Front Derailleur
N/A
Shift Levers
SRAM Rival 1, 1x11
Cassette
SRAM Rival, 11-speed, 11x42
Crank
SRAM Rival D1 Wide DUB, 40t XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
Bottom Bracket
SRAM DUB, press fit
Chain
SRAM Rival D1
Pedals
N/A
Wheels
Front Hub
Giant alloy, 12mm thru-axle
Rear Hub
Giant alloy, 12mm thru-axle
Rims
Giant P-X2 Disc wheelset, alloy
Spokes
Sapim
Tires
Maxxis Rambler, 700x45c, tubeless
Brakes
Brakes
SRAM Rival 1 hydraulic, Giant MPH rotors [F]160mm, [R]160mm
Brake Levers
SRAM Rival 1, left lever dropper switch
Cockpit
Stem
Giant Contact, 8-degree XS:50mm, S:60mm, M:70mm, M/L:80mm, L:80mm, XL:90mm
Handlebar
Giant Contact XR D-Fuse, 31.8mm XS:42cm, S:42cm, M:44cm, M/L:44cm, L:46cm, XL:46cm
Grips
Stratus Lite 3.0
Seat
Saddle
Giant Approach
Seatpost
Giant Contact Switch, dropper, 30.9mm XS:295mm, S:345mm, M:345mm, M/L:345mm, L:395mm, XL:395mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS Short | XS Long | SM Short | SM Long | MD Short | MD Long | MD/LG | MD/LG | LG Short | LG Long | XL Short | XL Long |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.46 mm | 1.5 mm | 1.5 mm | 1.52 mm | 1.52 mm | 1.55 mm | 1.55 mm | 1.56 mm | 1.56 mm | 1.55 mm | 1.55 mm |
| Bottom Bracket Height | 269 mm | 268 mm | 269 mm | 268 mm | 269 mm | 268 mm | 269 mm | 268 mm | 269 mm | 268 mm | 269 mm | 268 mm |
| Front Center | 612 mm | 612 mm | 608 mm | 608 mm | 613 mm | 613 mm | 618 mm | 618 mm | 628 mm | 628 mm | 643 mm | 644 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 78 mm | 82 mm | 72 mm | 75 mm | 68 mm | 72 mm | 65 mm | 68 mm | 65 mm | 68 mm | 65 mm | 68 mm |
| Stack | 552 mm | 552 mm | 566 mm | 566 mm | 582 mm | 582 mm | 598 mm | 598 mm | 612 mm | 612 mm | 626 mm | 626 mm |
| Reach | 377 mm | 377 mm | 377 mm | 377 mm | 383 mm | 383 mm | 387 mm | 387 mm | 393 mm | 393 mm | 403 mm | 403 mm |
| Top Tube Length | 536 mm | 536 mm | 546 mm | 546 mm | 556 mm | 556 mm | 571 mm | 571 mm | 581 mm | 581 mm | 596 mm | 596 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.4 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 430 mm | 430 mm | 450 mm | 450 mm | 470 mm | 470 mm | 490 mm | 490 mm | 510 mm | 510 mm | 530 mm | 530 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° | 71 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 125 mm | 125 mm | 135 mm | 135 mm | 150 mm | 150 mm | 165 mm | 165 mm | 180 mm | 180 mm | 195 mm | 195 mm |
| Chainstay Length | 426 mm | 436 mm | 426 mm | 436 mm | 426 mm | 436 mm | 426 mm | 436 mm | 426 mm | 436 mm | 426 mm | 436 mm |
| Wheelbase | 1025 mm | 1035 mm | 1021 mm | 1031 mm | 1026 mm | 1036 mm | 1031 mm | 1041 mm | 1041 mm | 1051 mm | 1057 mm | 1067 mm |
| Bottom Bracket Drop | 80 mm | 81 mm | 80 mm | 81 mm | 80 mm | 81 mm | 80 mm | 81 mm | 80 mm | 81 mm | 80 mm | 81 mm |
| Standover Height | 713 mm | 720 mm | 730 mm | 737 mm | 748 mm | 755 mm | 765 mm | 772 mm | 782 mm | 789 mm | 797 mm | 806 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 155 cm | 159 cm | 159 cm | 169 cm | 169 cm | 174 cm | 174 cm | 179 cm | 179 cm | 189 cm | 189 cm |
| Rider Max Height | 166 cm | 166 cm | 171 cm | 171 cm | 181 cm | 181 cm | 186 cm | 186 cm | 191 cm | 191 cm | 200 cm | 200 cm |
Model Overview
Revolt, Advanced 1 is a Giant Revolt model. Giant launched 68 bikes of this model so far. Take a sneak peek at all Giant Revolt bikes models from 2023, by clicking here.
Model range prices
Giant Revolt X 1 2023 is the most affordable bike of this model and has a price of 2603$. On the other hand, Giant Revolt X, Advanced Pro 0 2023, is the most expensive and costs 6800$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2023 and its price was 3500$. If we compare this with the average Gravel bike cost we notice that the price is 42.16% higher.
Revolt, Advanced 1 components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The Revolt, Advanced 1 2023 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Giant Revolt, Advanced 1 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Revolt, Advanced 1 comes in 12 sizes, that range from 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Giant Revolt, Advanced 1 includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
