Giant Stance E+ 1 Pro 29 2020
2020 E-bike
Estimate price |
4,200$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox Recon Silver RL
-
Groupset SX Eagle, SRAM -
Suspension Full -
Motor Yamaha 80Nm mid-drive -
Battery Giant EnergyPak Smart 500, 36V 13.8Ah integrated Lithium-Ion -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
163cm - 173cm
MD
170cm - 181cm
LG
178cm - 189cm
XL
186cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum, 120mm FlexPoint suspension system
Suspension Fork
RockShox Recon RL, 130mm travel, Lockout, 110x15mm MaxleLite
Rear Shock
RockShox Monarch RT, High Volume, 184x44mm, custom tuned
Drivetrain
Rear Derailleur
SRAM SX Eagle 12-speed
Front Derailleur
-
Shift Levers
SRAM SX Eagle 12-speed
Cassette
SRAM PG-1210, 11-50T, 12-Speed
Crank
SRAM X-Sync Eagle 38T 104BCD chainring Praxis e-Cadet+ custom forged crankarm set (Q-factor=168, S:160, M/L:165, XL:170)
Bottom Bracket
N/A
Chain
SRAM SX Eagle PowerLock, 12-speed
Pedals
-
Wheels
Front Hub
Giant eTracker Boost, Sealed cartridge bearing, 6-bolt, [F] 110x15 [R] 148x12mm Thru-axle
Rear Hub
Giant eTracker Boost, Sealed cartridge bearing, 6-bolt, [F] 110x15 [R] 148x12mm Thru-axle
Rims
Giant XCT 29 Tubeless Ready 25mm e-bike optimized
Spokes
Sapim E-Lite [r] Race [f], e-bike optimized
Tires
Maxxis Ardent 29x2.4" foldable, 60tpi Dual Compound EXO, Tubeless Ready
Brakes
Brakes
Shimano MT520, 4-piston brakes, 203mm
Brake Levers
Shimano MT501 Hydraulic Disc
Cockpit
Stem
Giant Contact
Handlebar
Giant Connect TR Riser 31.8x780mm
Seat
Saddle
Giant Contact, Neutral
Seatpost
Giant Contact Switch, dropper, 30,9mm (S:100/M:125/L:150/XL:170)
Motor & Battery
Motor
Giant SyncDrive Pro, 80Nm, 360% tuneable support, powered by YAMAHA. Pedal assist up to 20 mph.
Battery
Giant EnergyPak Smart 500, 36V 13.8Ah integrated Lithium-Ion
Remote
Giant RideControl ONE
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.41 mm | 1.36 mm | 1.33 mm |
| Bottom Bracket Height | 354 mm | 354 mm | 354 mm | 354 mm |
| Front Center | 698 mm | 719 mm | 745 mm | 772 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 106.9 mm | 106.9 mm | 106.9 mm | 106.9 mm |
| Stack | 596 mm | 605 mm | 614 mm | 628 mm |
| Reach | 411 mm | 428 mm | 450 mm | 471 mm |
| Top Tube Length | 586 mm | 606 mm | 631 mm | 656 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 406 mm | 432 mm | 482 mm | 507 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 135 mm |
| Chainstay Length | 471 mm | 471 mm | 471 mm | 471 mm |
| Wheelbase | 1168 mm | 1189 mm | 1215 mm | 1242 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 737 mm | 752 mm | 784 mm | 787 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 163 cm | 170 cm | 178 cm | 186 cm |
| Rider Max Height | 173 cm | 181 cm | 189 cm | 198 cm |
Model Overview
Stance E+ 1 Pro 29 is part of the Giant E Stance model. Giant released 29 e-bikes variations of this model so far. Take a sneak peek at all Giant E Stance e-bikes models from 2020, by clicking here.
Model range prices
Giant Stance E+ 2 2020 is the cheapest e-bike model and costs 2892$. Giant Stance E+ Pro 29 Electric Bike 2020 is the most expensive one and costs 4317$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail e-bikes
According to our calculations, the average cost of a Trail e-bike that is reliable is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
This e-bike was released in 2020 and its price was 4200$. Comparing the average cost of a Trail e-bike to this one, you will see that Stance E+ 1 Pro 29 price is 24.81% more expensive.
Overview of components
Fork
The fork installed on this bike is the RockShox Recon Silver RL model. The travel on this model is 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Giant Stance E+ 1 Pro 29 e-bike has the RockShox Monarch RT model installed, and has a travel of 120mm. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
When leaving the production line, the Stance E+ 1 Pro 29 model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 4 sizes. They vary from 163 cm – 198 cm (5.35 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
The Giant model is also equipped with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
