Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Suntour XCR Air
-
Groupset Deore -
Suspension Full -
Motor Yamaha 250W 70Nm mid-drive -
Battery EnergyPak Smart 625Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
163cm - 173cm
MD
170cm - 181cm
LG
178cm - 189cm
XL
186cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX Aluminum, 120mm FlexPoint suspension system, 141mm Boost QR, Integrated KS18 Kickstand Mount
Suspension Fork
SR Suntour XCR 34 Air LO-R, 130mm travel, tapered steerer, Lockout, 110x15 thru-axle
Rear Shock
RockShox Monarch R, High Volume, 184x44mm, custom tuned
Drivetrain
Rear Derailleur
Shimano Deore, 10-speed, Shadow+ LinkGlide
Shift Levers
Shimano Deore, 10-speed LinkGlide
Cassette
Shimano CS-LG600-10, 11-43T, 10-speed LinkGlide
Crank
Forged Alloy minimal Q-factor, 36T Steel Direct Mount ring (S:160, M/L:165, XL:170)
Bottom Bracket
N/A
Chain
Shimano, CN-LG500, 9/10/11speed for LinkGlide
Pedals
Aluminum Platform
Wheels
Front Hub
Giant eTracker Sport, [F] 15mm Thru-Axle [R] 141mm QR
Rear Hub
Giant eTracker Sport, [F] 15mm Thru-Axle [R] 141mm QR
Rims
Giant AM 29", Tubeless ready, 30mm inner width
Spokes
Stainless Steel
Tires
Maxxis Rekon 29x2.25" foldable, 60tpi, EXO, Tubeless Ready
Brakes
Brakes
Tektro HD-M745 Orion, 4-piston, hydraulic disc, 203mm
Brake Levers
Tektro HD-M745 Orion
Cockpit
Stem
Giant Contact
Handlebar
Giant Connect TR Riser 31.8x780mm
Seat
Saddle
Giant Sport
Seatpost
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
Motor & Battery
Motor
SyncDrive Sport, 70Nm, powered by Yamaha
Battery
EnergyPak Smart 625Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.43 mm | 1.37 mm | 1.34 mm |
| Bottom Bracket Height | 354 mm | 354 mm | 354 mm | 354 mm |
| Front Center | 692 mm | 713 mm | 739 mm | 766 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 113.6 mm | 113.6 mm | 113.6 mm | 113.6 mm |
| Stack | 599 mm | 609 mm | 618 mm | 632 mm |
| Reach | 410 mm | 427 mm | 450 mm | 471 mm |
| Top Tube Length | 586 mm | 606 mm | 631 mm | 656 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 406 mm | 432 mm | 482 mm | 507 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 135 mm |
| Chainstay Length | 481 mm | 481 mm | 481 mm | 481 mm |
| Wheelbase | 1172 mm | 1193 mm | 1219 mm | 1246 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 747 mm | 762 mm | 794 mm | 798 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 163 cm | 170 cm | 178 cm | 186 cm |
| Rider Max Height | 173 cm | 181 cm | 189 cm | 198 cm |
Model Overview
Stance E+ EX completes the Giant E Stance model. There are 29 e-bikes that carry this model name. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
The most economical model, the Giant Stance E+ 2 2022 has a starting price of 3629$. Giant Stance E+, EX Pro 2022 on the other hand is the most expensive at 5308$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail e-bikes average price
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2022 for 3687$. Comparing the average cost of a Trail e-bike to this one, you will see that Stance E+ EX price is 9.57% more expensive.
Stance E+ EX components
Fork
The Suntour XCR Air is included from the factory. It has a travel distance of 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The Stance E+ EX has a rear shock with a travel of 120mm. The model RockShox Monarch R is the one installed in this e-bike. Rear shocks improve riding comfort and give you greater control over all terrains. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
As for the wheels, Giant Stance E+ EX 2022, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Stance E+ EX comes in 4 sizes, that range from 163 cm – 198 cm (5.35 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
