Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 125mm -
Fork Suntour XCR
-
Groupset Deore, FSA -
Suspension Full -
Motor Yamaha 250W 75Nm mid-drive -
Battery EnergyPak Smart 625, EnergyPak Plus 250Wh range extender compatible -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
163cm - 173cm
MD
170cm - 181cm
LG
178cm - 189cm
XL
186cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum, 125mm travel FlexPoint suspension system, 148x12 rear axle, Universal Derrailleur hanger, 184x44 shock, 1.5~1.8" headset
Suspension Fork
SR Suntour XCR 34 LO-R, 140mm travel, tapered steerer, Lockout, 110x15 thru-axle
Rear Shock
SR Suntour Raidon R, 190x45mm, custom tuned
Drivetrain
Rear Derailleur
Shimano Deore LinkGlide, 10-speed
Front Derailleur
MRP HD2 co-moulded chain guide
Shift Levers
Shimano Deore LinkGlide
Cassette
Shimano LinkGlide, CS-LG400-10, 11-43T, 10-speed
Crank
FSA Comet E-Bike crank arm setFSA MegaTooth Direct-mount 1X steel 36T
Bottom Bracket
n/a
Chain
Shimano, LinkGlide, CN-LG500
Pedals
N/A
Wheels
Front Hub
Giant eTracker Boost, [F] 110x15 [R] 148x12mm
Rear Hub
Giant eTracker Boost, [F] 110x15 [R] 148x12mm
Rims
Giant AM, Tubeless ready, 30mm inner width [F] 27.5" (S size), 29" (M/L/XL size) [R] Giant AM 27.5", Tubeless ready, 30mm inner width
Spokes
Stainless Steel
Tires
Maxxis Rekon 27.5x2.4"(S size), 29x2.4" (M/L/XL size), Foldable, TLR, EXO, 60TPI [F], Maxxis Rekon 27.5x2.4" Foldable, TLR, EXO, 60TPI [R]
Brakes
Brakes
Tektro HD-M745 Orion, 4-piston, hydraulic disc, 203mm
Brake Levers
Tektro HD-M745 Orion
Cockpit
Stem
Giant Contact
Handlebar
Giant Connect TR Riser 31.8x780mm
Grips
Giant Connect ErgoMax lock-on
Seat
Saddle
Giant Sport
Seatpost
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
Motor & Battery
Motor
SyncDrive Sport, 75Nm, powered by Yamaha
Battery
EnergyPak Smart 625, EnergyPak Plus 250Wh range extender compatible
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.454 mm | 1.393 mm | 1.325 mm | 1.267 mm |
| Bottom Bracket Height | 315 mm | 315 mm | 315 mm | 315 mm |
| Front Center | 739 mm | 768 mm | 802 mm | 836 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 124 mm | 124 mm | 124 mm | 124 mm |
| Stack | 618 mm | 627 mm | 636 mm | 646 mm |
| Reach | 425 mm | 450 mm | 480 mm | 510 mm |
| Top Tube Length | 580 mm | 607 mm | 639 mm | 671 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 425 mm | 450 mm | 475 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 468 mm | 468 mm | 468 mm | 468 mm |
| Wheelbase | 1204 mm | 1233 mm | 1267 mm | 1301 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm | 40 mm |
| Standover Height | 760 mm | 760 mm | 780 mm | 796 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 163 cm | 170 cm | 178 cm | 186 cm |
| Rider Max Height | 173 cm | 181 cm | 189 cm | 198 cm |
About this model
Stance E+ EX completes the Giant E Stance model. Giant released 29 e-bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Giant Stance E+ EX 2023 is the most affordable e-bike of this model and has a price of 3904$. On the other hand, Giant Stance E+, EX Pro 2023, is the most expensive and costs 5839$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail e-bikes average price
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
At the moment of the release date, Giant Stance E+ EX price was 3904$. In conclusion, this e-bike price is 16.02% more expensive than the price of the average Trail e-bike.
Overview of components
Fork
The fork installed on this bike is the Suntour XCR model. The travel on this model is 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The shock that’s installed on this e-bike is SR Suntour Raidon R, with a travel distance of 125mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on Stance E+ EX are the 27.5″ aluminum type. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Stance E+ EX comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 163 cm – 198 cm (5.35 ft – 6.5 ft). In short, it won’t be difficult to find the right one for you.
