Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-grade composite, Electronic ready
Suspension Fork
Advanced-grade composite, Hybrid OverDrive steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tiagra
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiagra
Cassette
Shimano Tiagra 12x28, 10-speed
Crank
Shimano Tiagra, 34/50
Bottom Bracket
Shimano, Press Fit
Chain
KMC X10L
Pedals
N/A
Wheels
Front Hub
Giant Sport Tracker Road, 26h
Rear Hub
Giant Sport Tracker Road, 26h
Rims
Giant SR-2
Spokes
Stainless Steel, 14g
Tires
Giant P-SL 1, 700x23, Front and rear specific, Folding
Brakes
Brakes
Shimano Tiagra
Brake Levers
Shimano Tiagra
Cockpit
Stem
Giant Connect
Handlebar
Giant Contact, 31.8mm
Seat
Saddle
Giant Performance Road
Seatpost
Giant Variant, Composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.403 mm | 1.412 mm | 1.45 mm | 1.445 mm | 1.444 mm |
| Stack | 517 mm | 529 mm | 545 mm | 567 mm | 581 mm | 595 mm |
| Reach | 372 mm | 377 mm | 386 mm | 391 mm | 402 mm | 412 mm |
| Top Tube Length | 515 mm | 535 mm | 555 mm | 570 mm | 585 mm | 605 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° | 72 ° |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 120 mm | 133 mm | 148 mm | 168 mm | 188 mm | 203 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 972 mm | 974 mm | 980 mm | 986 mm | 1001 mm | 1021 mm |
| Standover Height | 724 mm | 742 mm | 765 mm | 787 mm | 805 mm | 823 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
About this model
TCR Advanced 3 is a Giant Tcr model. 260 bikes variations carry this model name so far. Take a sneak peek at all Giant Tcr bikes models from 2016, by clicking here.
Model range prices
Giant TCR Advanced 3 2016 is the cheapest bike model and costs 1600$. Giant TCR Advanced SL 0 2016 is the most expensive one and costs 8800$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Race bikes average price
Our math shows that the average cost of a dependable Race bike is 3350$. However, even if your budget is less than the average, you might still be able to get a top-quality Race bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1600$. Comparing the average cost of a Race bike to this one, you will see that TCR Advanced 3 price is 109.38% smaller.
TCR Advanced 3 components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on TCR Advanced 3 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The TCR Advanced 3 has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
Sizes
This bike is available in 6 sizes. They vary from 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
