Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
157cm - 169cm
SM
165cm - 175cm
MD
171cm - 181cm
MD/LG
177cm - 187cm
LG
183cm - 193cm
XL
189cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced grade composite, 12mm thru-axle
Suspension Fork
Advanced grade composite, full composite OverDrive steerer, 12mm thru-axle
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano Ultegra
Shift Levers
Shimano Ultegra, 22sp
Cassette
Shimano 105, 11-30T, 11sp
Crank
Shimano Ultegra, 36-52T
Bottom Bracket
Shimano press fit
Chain
KMC X11EL-1
Pedals
N/A
Wheels
Front Hub
Giant sealed disc alloy, 24H
Rear Hub
Giant sealed disc alloy, 24H
Rims
Giant PR2 disc tubeless
Spokes
Stainless steel, 14-15g
Tires
Giant Gavia Course 1, 700x25c (28mm wide)
Brakes
Brakes
Shimano Ultegra hydraulic disc, Fr: 160, Rr: 140mm
Brake Levers
Shimano Ultegra hydraulic
Cockpit
Stem
Giant Contact, 8 degree
Handlebar
Giant Contact, 31.8mm
Seat
Saddle
Giant Approach
Seatpost
Giant Variant composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.39 mm | 1.41 mm | 1.44 mm | 1.46 mm | 1.46 mm |
| Bottom Bracket Height | 264 mm | 266 mm | 266 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 582 mm | 582 mm | 585 mm | 595 mm | 610 mm | 624 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 72.1 mm | 64 mm | 59.2 mm | 59.2 mm | 59.2 mm | 59.2 mm |
| Stack | 508 mm | 519 mm | 536 mm | 553 mm | 572 mm | 587 mm |
| Reach | 367 mm | 374 mm | 379 mm | 384 mm | 393 mm | 403 mm |
| Top Tube Length | 511 mm | 526 mm | 541 mm | 556 mm | 571 mm | 591 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 425 mm | 445 mm | 470 mm | 500 mm | 530 mm | 560 mm |
| Head Tube Angle | 71 ° | 72.3 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 120 mm | 130 mm | 145 mm | 165 mm | 185 mm | 200 mm |
| Chainstay Length | 396 mm | 396 mm | 396 mm | 396 mm | 396 mm | 396 mm |
| Wheelbase | 967 mm | 968 mm | 971 mm | 982 mm | 997 mm | 1011 mm |
| Bottom Bracket Drop | 72 mm | 69 mm | 69 mm | 67 mm | 67 mm | 67 mm |
| Standover Height | 697 mm | 716 mm | 738 mm | 764 mm | 791 mm | 807 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 165 cm | 171 cm | 177 cm | 183 cm | 189 cm |
| Rider Max Height | 169 cm | 175 cm | 181 cm | 187 cm | 193 cm | 199 cm |
Model Overview
TCR Advanced Disc 1 is a Giant Tcr model. 260 bikes variations carry this model name so far. Take a sneak peek at all Giant Tcr bikes models from 2021, by clicking here.
Model range prices
Giant TCR Advanced 2 2021 is the most affordable bike of this model and has a price of 1952$. On the other hand, Giant TCR Advanced SL Disc 0 2021, is the most expensive and costs 11850$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Race bikes average price
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2021 for 2547$. Doing a quick comparison, we notice that TCR Advanced Disc 1 price is 31.53% lower than the average cost of a Race bike.
TCR Advanced Disc 1 components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The TCR Advanced Disc 1 2021 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Giant TCR Advanced Disc 1 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This bike is available in 6 sizes. They vary from 157 cm – 199 cm (5.15 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
