Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-grade composite
Suspension Fork
Advanced-grade composite, Full-composite OverDrive 2 steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano Ultegra
Shift Levers
Shimano Ultegra
Cassette
Shimano Ultegra 11x28, 11-speed
Crank
Shimano Ultegra, 36/52
Bottom Bracket
Shimano, Press fit
Chain
KMC X11 EL
Pedals
N/A
Wheels
Front Hub
Giant SLR 1 DBL WheelSystem; Pawl driver, [F] 16h [R] 21h
Rear Hub
Giant SLR 1 DBL WheelSystem; Pawl driver, [F] 16h [R] 21h
Rims
Giant SLR 1 DBL WheelSystem; 30mm deep, 23mm wide, Tubeless compatible, Full composite
Spokes
Giant SLR 1 DBL WheelSystem; Aerolite bladed stainless
Tires
Giant Gavia SLR Tubeless, 700x25, Folding
Brakes
Brakes
Shimano Ultegra
Brake Levers
Shimano Ultegra
Cockpit
Stem
Giant Contact SL, OverDrive 2
Handlebar
Giant Contact SL, 31.8mm
Seat
Saddle
Giant Contact SL Forward, SST tubular rails
Seatpost
Giant Variant, Composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.41 mm | 1.43 mm | 1.43 mm | 1.46 mm | 1.45 mm |
| Bottom Bracket Height | 266 mm | 268 mm | 268 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 577 mm | 579 mm | 581 mm | 601 mm | 611 mm | 625 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 70 mm | 60 mm | 57 mm | 57 mm | 57 mm | 57 mm |
| Stack | 508 mm | 520 mm | 536 mm | 558 mm | 572 mm | 586 mm |
| Reach | 363 mm | 369 mm | 374 mm | 389 mm | 393 mm | 403 mm |
| Top Tube Length | 506 mm | 526 mm | 541 mm | 561 mm | 571 mm | 596 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° | 72 ° |
| Seat Tube Length | 425 mm | 445 mm | 470 mm | 500 mm | 525 mm | 550 mm |
| Head Tube Angle | 71 ° | 72.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 123 mm | 133 mm | 148 mm | 168 mm | 188 mm | 203 mm |
| Chainstay Length | 396 mm | 396 mm | 396 mm | 396 mm | 396 mm | 396 mm |
| Wheelbase | 963 mm | 965 mm | 967 mm | 988 mm | 998 mm | 1012 mm |
| Bottom Bracket Drop | 70 mm | 68 mm | 68 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 715 mm | 733 mm | 756 mm | 778 mm | 796 mm | 814 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
Model Overview
TCR Advanced Pro 1 is a Giant Tcr model. There are 260 bikes that carry this model name. Take a sneak peek at all Giant Tcr bikes models from 2017, by clicking here.
Model range prices
The most economical model, the Giant TCR Espoir 24 2017 has a starting price of 700$. Giant TCR Advanced SL 0-DA Di2 2017 on the other hand is the most expensive at 8550$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Race bikes
According to our math, the average price for a trustworthy Race bike is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Giant released this model in 2017, its price was 3150$. Comparing the average cost of a Race bike to this one, you will see that TCR Advanced Pro 1 price is 6.35% smaller.
TCR Advanced Pro 1 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When leaving the production line, the TCR Advanced Pro 1 model has 700c carbon wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Giant TCR Advanced Pro 1 is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
TCR Advanced Pro 1 comes in 6 sizes, that range from 155 cm – 200 cm (5.09 ft – 6.56 ft). In short, you can easily find one that suits you.
