Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Giant Composite Technology
Suspension Fork
Advanced-Grade Composite, Alloy OverDrive Steerer
Rear Shock
N / A
Drivetrain
Rear Derailleur
Shimano 105 5700
Front Derailleur
Shimano 105 5700
Shift Levers
Shimano 105 5700
Cassette
Shimano 105 5700 11x28, 10-Speed
Crank
Shimano 105 5700, 34/50
Bottom Bracket
Shimano Dura-Ace, Internal Press Fit
Chain
Shimano 105
Pedals
Not Included
Wheels
Front Hub
Formula Sealed Cartridge Bearing 24/28h
Rear Hub
Formula Sealed Cartridge Bearing 24/28h
Rims
Giant P-R2
Spokes
Sapim Race, 14/15g
Tires
Michelin Dynamic, 700x23
Brakes
Brakes
Tektro TK-R540 Giant Specific, Dual Pivot
Brake Levers
Shimano 105 5700
Cockpit
Stem
Giant Connect
Handlebar
Giant Connect, 31.8
Seat
Saddle
Giant Performance Road, Men's
Seatpost
Giant Vector Composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Top Tube Length | 520 mm | 535 mm | 555 mm | 570 mm | 585 mm | 605 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 73 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 120 mm | 135 mm | 150 mm | 170 mm | 185 mm | 200 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 977 mm | 974 mm | 980 mm | 986 mm | 1001 mm | 1021 mm |
| Standover Height | 724 mm | 742 mm | 765 mm | 787 mm | 805 mm | 823 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
Model Overview
TCR Composite completes the Giant Tcr model. Giant launched 260 bikes of this model so far. Take a sneak peek at all Giant Tcr bikes models from 2011, by clicking here.
Model range prices
Giant TCR Composite 2011 is the most economical model, with a starting price of 1950$. Giant TCR Advanced SL 0 2011 on the other hand costs 13000$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Race bikes average price
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Giant TCR Composite price was 1950$. In conclusion, this bike price is 71.79% smaller than the price of the average Race bike.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When leaving the production line, the TCR Composite model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Giant TCR Composite has Rim brakes installed. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
Sizes
This bike is available in 6 sizes. They vary from 155 cm – 200 cm (5.09 ft – 6.56 ft). In short, it won’t be difficult to find the right one for you.
