Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Rival -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-Grade Aluminum w/ Eyelets
Suspension Fork
Advanced-Grade Composite, Alloy OverDrive Steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM Rival
Front Derailleur
SRAM Rival
Shift Levers
SRAM Rival
Cassette
SRAM PG-1050 11x28, 10-Speed
Crank
SRAM Rival, 38/46
Bottom Bracket
SRAM GXP, Press Fit
Chain
KMC X10
Pedals
N/A
Wheels
Front Hub
Giant Sealed Bearing, 24/28h
Rear Hub
Giant Sealed Bearing, 24/28h
Rims
Giant P-R2, Double Wall
Spokes
DT Swiss Competition, 14/15g
Tires
Kenda Slant 6, 700x32, Folding
Brakes
Brakes
TRP CX
Brake Levers
SRAM Rival w/ Tektro RL721 Top Bar Levers
Cockpit
Stem
Giant Connect SL
Handlebar
Giant Connect SL, 31.8
Seat
Saddle
Giant Performance Road, Men's
Seatpost
Giant Connect SL, Composite, 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD | LG | XL |
|---|---|---|---|---|---|
| Top Tube Length | 535 mm | 545 mm | 560 mm | 575 mm | 590 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 130 mm | 145 mm | 160 mm | 175 mm | 190 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1016 mm | 1022 mm | 1032 mm | 1042 mm | 1052 mm |
| Standover Height | 787 mm | 805 mm | 826 mm | 841 mm | 861 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 180 cm | 189 cm | 199 cm |
Model Overview
TCX 1 belongs to the Giant Tcx model. There are 95 bikes that carry this model name. Check out the entire range from 2013 of this model, by clicking this link.
Model range prices
Giant TCX 2 2013 is the cheapest bike model and costs 1050$. Giant TCX Advanced 0 (2014) 2013 is the most expensive one and costs 7150$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Cyclocross bikes average price
According to our math, the average price for a trustworthy Cyclocross bike is 2012$. However, this doesn’t mean that if you spend less money on a Cyclocross bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Giant TCX 1 price was 1850$. If we compare this with the average Cyclocross bike cost we notice that the price is 8.76% lower.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The TCX 1 2013 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The TCX 1 has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Giant TCX 1 bike has 5 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
